XY-2 Four Wheel Trailer Drill Machine 300-600m Geological Exploration Drilling Well Diamond Core Drilling Rig
Price:
Negotiation
MOQ:
1 set
Delivery Time:
7-12 days
Brand:
JINZHOU SHITAN
Product Description
XY-2 four wheel Trailer Drill Machine 300-600m Geological Exploration Drilling Well Diamond Core Drilling Rig
XY-2 four wheel trailer drill machine is mainly adapted to suit for engineering exploration, water well and foundation hole drilling, it can also be used in mineral exploration with diamond bit or tungsten-carbide tipped bit. Thie equipment is compact in structure, small in size, light in weight and convenient in transportation. It is with big spindle dia. which is cery suitable for engineering construction.
| 1.Unity Machine Parameter | |
| Drilling Depth(m) | 150~200m |
| Hole Diameter(mm) | 75~200mm |
| Drill Rod Diameter | 50 |
| Drilling Angle | 90~75 |
| Drill Weight (No include power) | 910kg |
| Overall Dimession | 2750*950*1600mm |
| 2.Spindle | |
| Spindle Speed | 64, 128, 287, 557r/min |
| Spindle Stroke | 450mm |
| 3.Hoist | |
| Max. Single Line Hoisting Capacity | 2000kg |
| Reel Lifting Speed | 75, 151rm/s |
| Tightrope Diameter | 13mm |
| Tightrope Cubic Measure | 35mm |
| Hug Follgate Belt Width | 70mm |
| Distance Between Drill and Hole | 400mm |
