Yellow 6m Rod Water Well Drilling Rig High Efficiency 350 Meters
Top Quality Yellow Color High Drilling Effeciency ST 350 Meters Water Well Drilling Rig
Introduction High Drilling Effeciency ST 350 Meters Water Well Drilling Rig
water well drilling rig is a lightweight, efficient, versatile drilling hole equipment, which borehole drilling machine is mainly applied in drilling wells, irrigation wells, geothermal wells and air holes for other purposes, especially for mountain and rock formation water engineering. The water well drilling rig machine can work on different formations, well drilling diameter up to 245mm.
Tech Datas Of 350 water well drilling rig
| Technical Parameters of ST300 water well drilling rig | |
| type | ST350 |
| The weight | 9.8T |
| Dimension |
6m×2m×2.5m |
| The hole diameter |
105-305mm |
| Drilling depth | 350m |
| One-time advance length | 6m |
| Walking speed | 2.5KM/H |
| Climbing angles | 30 |
| Power | 92KW |
| Using air pressure | 1.7-3.3MPA |
| Air consumption | 17-35 |
| Drill pipe length | 1.5m 2.0m 3.0m 6.0m |
| Drill pipe diameter | 89mm,102mm, |
| Rig lifting force | 20T |
| Swing speed | 55-115rpm |
| Swing torque | 6200-85000N.m |
Characteristics of High Drilling Effeciency ST 350 Meters Water Well Drilling Rig
The drill machine adopts new hydraulic technology, supporting high torque hydraulic motor rotation and big bore drill hydraulic propulsion, branded multi-cylinder engine-powered two-stage air filter and the intake air compressor designed for hydraulic systems, extend the life of diesel engines. Unique pump design to facilitate maintenance, reduce maintenance costs. Centralized hydraulic control console, easy to operate.
FAQ Of High Drilling Effeciency ST 350 Meters Water Well Drilling Rig
Q: Are you factory or trade company?
