Shitan ST200 Crawler Mounted Water Well Drilling Rig 90-152mm 25m Depth
St 200 Crawler Mounted Large Water Well Borehole Drilling Rig For Deep Underground
ST 200 Crawler Mounted Drill Rig Description
Full hydraulic drilling rig mainly used to drilling wells,irrigation wells,ground source heating pump wells and boreholes for other purposes,especially for mountain and rock formation well projects.The rig can be drill in different layers.
ST 200 Crawler Mounted Drill Rig Parameter
| Model | ST 200 |
| Condition | New |
| Type | Rotary Drilling Rig |
| Power Type | Diesel |
| Origin | China |
| Brand Name | Shitan |
| Usage | Water Well Drilling |
| Dimension(L*W*H) | 6400MM*2250MM*2700MM |
| Weight | 5800KG |
|
Certification
|
ISO9000 |
| Warranty | 1 YEARS |
| Marketing Type | New Product 2020 |
| Drilling diameter | 90-152mm |
| Depth | 25M |
| Rotary speed | 0-90rpm |
| DTH | K40 |
| Drilling Rods | 76*2m+76*3m |
| Air consumption | 13-20m3/min |
| taavelling speed | 0-2.5km/h |
ST 200 Crawler Mounted Drill Rig Advantages
Our Company Experienced Many Years Of High-speed Development, Gathering Large Number of Talents andWinning Sound Reputation and Credibility. Our Product Quality, Rapid and Healthy Development Ensured ByConvenient Transportation Network, Advanced Management Concepts, and Comprehensive ManagementSystem.
Our Company Goal
We insist on the strategy of technology research and development. Technical design, material purchasing, precised manufacturing and strict quality inspection Sincerely hope we can establish close,trustworthy and long term relationship with each customers. Any interests and needs about our Drilling rigs,please contact us.
Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：
Pneumatic Drilling Rig / Air Drilling Rig（ST-180,ST-200,ST-260,ST-300,ST-350,ST-400,ST450,ST-450,ST-500, ST-600,ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B,GK180, GK200, GY150, GY200 and 30 impact drill rig,ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter
Good quality, professional after-sales service, welcome to order
