Gk 200 Borehole Water Well Geological Drilling Rig Machine With BW 160 Mud Pump
GK 200 Hole Drilling Sample Collecting Small Borewell Geological Drilling Rig Machine
Product Introduction
It is widely utilized and featured in high power and hoisting load(2T), large torque transmission, etc. The rotating speed of vertical hexagonal spindle varies between 71r/min-825r/min.The drill rig reserves some functional interfaces in the hydraulic system, and can expand the functions according to the technological requirements of different users.
Product Technical Data
| GK 200 drilling depth | 200m |
| Rated boring diameter | 200mm |
| Vertical shaft rotation speed (4 shifts) | 118, 236, 505, 1010.r/min |
| Vertical shaft max. output torque | 1500N*m |
| Max. hositing weight single line) | 17KN |
| Drilling rod diameter | 42mm |
| Drilling dip angle | 90~75° |
| Drill outside diameter (L*B*H) | 1433*697*1273mm |
| Drill weight | 500kg |
| Max diameter | 300mm |
Product Advantages
1. With hydraulic automaatic feeding device, elevated drilling efficiency.
2. Large torque and drilling diameter.
3. With a spherial jaw holding mechanism and the rod replacement without breakdwn
4. Compact structure, small volume, lightweight, high detachability,
5. Adoping large drive pipe, double guide rod, increase the stability.
The GK 200 is specifically designed for high drilling efficiency, making it the ideal choice for exploration drilling and diamond sampling. Its advanced technology and robust construction allow for precise and accurate drilling, resulting in high-quality samples and data collection.
Invest in the GK 200 Geological Drilling Rig and experience the benefits of high drilling efficiency in your next drilling project. Contact us now for more information and to request a quote.
GK 200 Geological Drilling Rig Machine FAQ
Q 1: What kind of drilling rig do you have?
A: We mainly produce small hydraulic drilling rig, water well drilling rig, core drilling rig, engineering drilling rig, geological exploration drilling rig, etc., and we will recommend the suitable model according to your exact requirement .
Q 2: Where is the address of your company?
A: Our factory is in Jinzhou, Shijiazhuang City, Hebei Province, China
Q 3: Are you a manufacturer or a trading company?
A:We are a 20 years professional manufacturer with ISO certificate. We have a large modern drilling rig plant in Hebei, China.
Q 4: How long is your delivery time?
A: Small hydraulic drilling rigs generally take 5-7 days, and large pneumatic water well drilling rigs generally take 7-15 days. If there is an urgent order, please contact our sales in advance.
Q 5: How long is the warranty of your well drilling rig?
A: Except for consumable spare parts, the whole machine shall be one year.
Q6: How long can your air compressor be used?
A: Normally more than 10 years.
Q 7: What are the terms of payment?
A: TT, Western Union transfer.
Q8, Can you provide us with the documents for customs clearance?
A: Of course. We will send you commercial invoice, sales contract, packing list, bill of lading (FOB or CFR, CIF terms), insurance policy (if CIF terms), and certificate of origin if you need it
