Hsinda Factory Supply RAL Color Black Sandy Texture Powder Coating Dry Paint Spray for Outdoor Lamp Polyester Powder Coat
Hsinda Factory Supply RAL Color Black Sandy Texture Powder Coating Dry Paint Spray for Outdoor Lamp Polyester Powder Coat
Product detail
1.Hsinda Powder Coating Powder Specification
| Type |
Epoxy Powder Coating; Polyester Powder Coating; Epoxy-Polyester Powder Coating |
| Color | RAL&Pantone color |
| Surface Finish | Superior gloss and color retention |
| Particle Size | Average 32-42μm |
| Specific Gravity | 1.2-1.7g per cubic meter |
| Coverage | 8-10 square meters per Kg at 30-90 μm film thickness |
| film thickness | Not less than 100μm |
2.Hsinda Powder Coating Powder Apply Instruction
| Application Voltage | 60-90 KV |
| Gun to Component Distance | 15-30CM |
| Curing Temperature | 180-200℃,10 min-15 min |
3.Hsinda Powder Coating Powder Quality Test
| Test Item | Test Method | Test Result |
| Film Thickness | ISO2360 | 60-80um |
| Pencil Hardness | ASTMD 3363 | HB-H |
| Bending | ISO1519 | ≤10mm |
| Grid Test 1mm | ISO2409 | 0 Class |
| Impulse Test | ASTMD2794 | Pass |
| Cupping Test | ISO1520 | ≥8mm |
| Heat Resistance 1000 hours | ISO6270-1 | Popping<1mm |
| Salt Spray 1000 hours | ISO9227 | Corrosion Spreading<1mm |
What is Powder Coating?
Powder coating is a new type of 100% solid powder coating which does not contain solvents. With no solvent, no pollution, energy and resources saving, recycling, environmental protection, higher performance, low health risk to workforce, economical advantages etc.
Most powder coating is used by electrostatic spraying on metal surface, and then cure in oven, eventually form a solid layer.
Finishes
- Gloss
- Matte
- Textured
- Metallic
Applications of Hsinda Powder
Automotive industry
Architectural applications
Furniture and home decor
Industrial equipment
Consumer goods
Hsinda are an associated factory
1.More than 20% of managements & technical experts abroad and superior European chemical technology.
2.Our factory Quickly grow up to be the Europe’s & Middle East RELIABLE powder coating Supplier with SGS,Tuv, Rohs, ISO Certificate .
3.Now we own Third Bonding System especially for produce Metallic powder coating and had developed high temperature resistant powder coatings and MDF powder coating.
4.With our concept of "Quality first, Credit first, Service first"
| Trade Terms | FOB, CIF, CRF, CNF |
| Payment Terms | T/T, L/C, West Union, PayPal etc. |
| Delivery time | 3-7 days after payment |
| Packaging | Size: 39*26*43 (unit:cm) Weight: N.W. 25kg G.W. 26kg |
| Shipping | By sea, by air, by courier |
