antique hammer tone powder coat paint for outdoor metal coating
Factory Sale Antirust Hammer Tone Powder Paint for Carbon Steel Shelf Polyester Powder Coating
Most powder coating is used by electrostatic spraying on metal surface, and then cure in oven, eventually form a solid layer.
Powder Types & Application Table
The powders most commonly used in the Powder Coating Industry are epoxy, polyesters, nylon, PVC, and to a lesser extent polyurethane and acrylic. There is also a Hybrid, an epoxy/polyester mix that is also often used.
We at Woncheng use mainly epoxy, polyester and epoxy/polyester. These three types of powder cover most of our customers application requirements.
Product detail
1.Hsinda Powder Coating Powder Specification
| Type |
Epoxy Powder Coating; Polyester Powder Coating; Epoxy-Polyester Powder Coating |
| Color | RAL&Pantone color |
| Surface Finish | Superior gloss and color retention |
| Particle Size | Average 32-42μm |
| Specific Gravity | 1.2-1.7g per cubic meter |
| Coverage | 8-10 square meters per Kg at 30-90 μm film thickness |
| film thickness | Not less than 100μm |
2.Hsinda Powder Coating Powder Apply Instruction
| Application Voltage | 60-90 KV |
| Gun to Component Distance | 15-30CM |
| Curing Temperature | 180-200℃,10 min-15 min |
3.Hsinda Powder Coating Powder storage stability
| ♦Store in ventilated, dry, clean room, temperature < 25℃ | ♦Relative humidity 50-65% |
| ♦Away from direct sunlight, fire, heat | ♦For best performance, use within 6 months |
| Test Item | Test Method | Test Result |
| Film Thickness | ISO2360 | 60-80um |
| Pencil Hardness | ASTMD 3363 | HB-H |
| Bending | ISO1519 | ≤10mm |
| Grid Test 1mm | ISO2409 | 0 Class |
| Impulse Test | ASTMD2794 | Pass |
| Cupping Test | ISO1520 | ≥8mm |
| Heat Resistance 1000 hours | ISO6270-1 | Popping<1mm |
| Salt Spray 1000 hours | ISO9227 | Corrosion Spreading<1mm |
What is Powder Coating?
Powder coating is a new type of 100% solid powder coating which does not contain solvents. With no solvent, no pollution, energy and resources saving, recycling, environmental protection, higher performance, low health risk to workforce, economical advantages etc.
Most powder coating is used by electrostatic spraying on metal surface, and then cure in oven, eventually form a solid layer.
Comparative Analysis with Liquid Paint: While liquid paint offers greater color flexibility and can be applied to a wider range of substrates, powder coating excels in terms of environmental impact, durability, and cost-effectiveness, particularly for large-scale industrial applications.
Applications of Hsinda Powder
Powder coating is widely used in various industries, including automotive, aerospace, construction, furniture, and appliances, to provide decorative and protective finishes on metal, plastic, and composite substrates.
| ♦ Electrical Household Appliances | ♦ Aerospace Area |
| ♦ Automotive Electronics | ♦ Fitness Equipment |
| ♦ Track Traffic | ♦ Medical Devices |
| ♦ Petroleum Pipes, Valve | ♦ Tools & Hardware |
| ♦ LED Lights, Outdoor Lamps | ♦ Radiator & Heat Sink |
| ♦ Glass Decoration | ♦ External Facilities |
| Trade Terms | FOB, CIF, CRF, CNF |
| Payment Terms | T/T, L/C, West Union, PayPal etc. |
| Delivery time | 3-7 days after payment |
| Packaging | Size: 39*26*43 (unit:cm) Weight: N.W. 25kg G.W. 26kg |
| Shipping | By sea, by air, by courier |
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
