Industrial Deionized EDI Water Plant , Edi Water Treatment Plant 1 M3/Hr Capacity

RO Plant Fitting Water Reverse Osmosis And Edi Filter System Industrial Deionized Water Systems

Product Grouping

The advantages are:

1. Continuous production,no need for acid and alkali regenerating, without the emission of acid and alkali solution

2. Stable quality of output water

3. Low woking cost,standard design

4. Compact structure

5 Convenient operation and management

Application Field:

1. semiconductoe industry

2. electronic industry

3. power plant

4. chemcial industry

5. petroleum industry

6. metallurgy industry

7. pharmaceutical indusry

8. food and beverage industry

9. pilp&paper industry

10. automatic industry and many other industries

EDI(Electrodeionization) technology scientifically combine electrodialysis with ion exchang technology and substitutes the traditional ion exchang bed technique.

specification	notes	working range	optimum performance
feedwater source	RO water , direct feed , or with intermediate break tank plus filter
EDI feed conductivity	ionic load determines size of the working bed and polishing bed within the EDI	1-20us/cm	1-6us/cm
feed conductivity equivalent		less than 50us/cm	less than 10us/cm
PH	low ph feedwater typically indicators the presence of CO2 which will decrease quality	5.0-9.5	7.0-7.5
total CO2		less than 5mg/l	less than 2mg/l
temperature		5℃to 40℃	20℃to30℃
hardness		less than 1.0ppm at 90% recovery
organics	TOC	less than 0.5ppm	not detectable
metals	Fe,Mn,transition metals	less than 10ppb	not detectable
silica , SiO2	typically dissolved , reactive	less than 0.5ppm	less than 0.2ppm
oxidizers	Cl2 and O3 typically	not detectable	not detectable
particles	recommended direct feed particle - free RO permeate , or 1μm pre - filtration of feed from intermediate tank	SDI less than 1	SDI less than 0.5

Product functional component description

1. Original water tank: liquid level controller unstable municipal water supply, with using the original water tank
storage system for water supply to meet the subsequent water use.
2. Mechanical filter: remove sand, mud, rust and other suspended solids and colloidal impurities from water. Automatic operation, washing, backwashing.
3. Full automatic activated carbon filter: the removal of organic impurities, part of the smell, removal of residual
chlorine. Automatic operation, washing, backwashing.
4. Automatic water softener: water softening, removal of the ion that is easy to form rigidity, such as Ca2+, Mg2+. Automatic operation, washing, backwashing, regeneration.
5.The salt box: filled with regeneration agent, used in water softener regeneration.
6. Security filter: remove the M >5 particles in the water to prevent clogging of the reverse osmosis membrane.
7. High pressure pump: pressure on RO reverse osmosis water
8. Fully automatic reverse osmosis
9. Pure water tank: water storage
10. Pure water pump: pressure on the water inlet. Pure water tank liquid level is higher than the high level and the ultra pure water tank liquid level is lower than the low water level, pure water pump starts.
12. Ultra pure water tank: storage of ultra pure water
