SUS 304 Terminal HEPA Filter High Temperature Resistance For Electronics Industry
H14 SUS 304 Heat-Resistant High Temperature Resistance separator HEPA Air Filter
Applications
Mainly used for the requirements of the electronics industry, coating industry,chemical industry high-temperature air purification equipment and system.
Features
- perature resistance HEPA filter
- High efficiency
- Low resistance
- Large dust holding capacity
- High-temperature resistance, can work in 250℃-350℃
- Application: It is applied to some equipment and systems
- like oven which the clean air is required
- Type: high-temperature resistance filter
- Final resistance: (suggested) ≤600Pa
- Temp. resistance: ≤350℃
- Humidity: ≤100%RH
- Dimension(mm): 610*610*120
- Rated air flow(m3/h): 620
- Filter area(m3/h): 7.7
- Dust holding capacity: 370
- Initial pressure@0.5m/s air speed (Pa):≤220
- Final pressure (Pa):400
- Filter efficiency 0.3 μm (%):99.97
| • High temperature • High mechanical strength • High efficiency • High air volume |
Recommended final pressure drop: 500 Pa. Temperature:150°C 250°C 300°C 350°C. |
Standard Size
We not only produce all kinds of different normal size High temperature resistance Separator HEPA filter,but also accept all kinds of customized
size High temperature resistance Separator HEPA filter.Please choose what size you want to buy refer to the below table,
| Model Dimensions (W×H×D) mm |
Filter grade EN 779/EN1822 |
Airflow / pressure drop m³/h / Pa (± 15%) | Unit volume m³ |
| 305x610x292 | M6 | 1700/100 | 0.054 |
| 610x610x292 | M6 | 3400/100 | 0.108 |
| 305x610x292 | F8 | 1700/135 | 0.054 |
| 610x610x292 | F8 | 3400/135 | 0.108 |
| 305x610x150 | H13 | 500/220 | 0.028 |
| 610x610x150 | H13 | 1000/220 | 0.056 |
| 915x610x150 | H13 | 1500/220 | 0.084 |
| 305x610x292 | H13 | 1250/220 | 0.054 |
| 610x610x292 | H13 | 2500/220 | 0.108 |
| 305x610x150 | H14 | 500/220 | 0.028 |
| 610x610x150 | H14 | 1000/220 | 0.056 |
| 915x610x150 | H14 | 1500/220 | 0.084 |
| 305x610x292 | H14 | 1250/220 | 0.054 |
| 610x610x292 | H14 | 2500/220 | 0.108 |
FAQ
Q1. Are you a manufacturer?
Yes, we are a high-tech enterprise which with 20 years experience in developing and manufacturing various filters and purification equipments.
Q2. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your
branded boxes after getting your authorization letters.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 7 to 15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of
your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
