Electronics HEPA Terminal Box Replaceable Pharmaceutical ISO Extremely Durable
Price:
negotiable
MOQ:
1 unit
Delivery Time:
Negotiable
Brand:
indair
Product Description
Replaceable Pharmaceutical ISO Terminal Box HEPA box for electronics
Basic Info
After-Sales Service: Technical Support Available
Air Direction: Top or Side
Filter Grade: H13 or H14
DOP Test: Available
Collar: Square / Round
Diffuser: Various
Trademark: Indair
Transport Package: Pallet
Specification: Various
Origin: Suzhou, China
Typical Applications
Product Overview
| Pharmaceutical | Microelectronics |
| Healthcare | Food and Beverage |
Product Overview
Lightweight cold-roll steel sheet or stainless steel
Room side replaceable filter access
Welded construction for strength and leak-free operation
Easy access for filter testing
Available with micro glass HEPA or ULPA media or extremely durable, low pressure drop ePTFE
Available with micro glass HEPA or ULPA media or extremely durable, low pressure drop ePTFE
Stainless steel removable protective grill
Vertical or horizontal flow applications
Adjustable butterfly damper
Designed for tee grid or plaster ceiling applications
Wall-mounted model available
Removable perimeter trim
|
Model
|
Installation dimension of the box
B*A*Hmm |
Installation dimension of the box
B*A*H mm |
Nominal air flow rate m3/h
|
Nominal air flow rate m3/h
|
Pipe connection dimension
E*F mm |
External Dimension of the box
T*S*R mm |
Weight(kg)
|
|
Ceiling air supply
|
|||||||
|
GWT320
|
370*370*220
|
320*320*80
|
360
|
200*200
|
250*250
|
430*430*268
|
12
|
|
GWT350
|
400*400*220
|
350*350*80
|
450
|
200*200
|
250*250
|
460*460*268
|
14
|
|
GWT400
|
450*450*220
|
400*400*80
|
500
|
200*200
|
250*250
|
510*510*268
|
15
|
|
GWT484
|
534*534*220
|
484*484*80
|
800
|
320*200
|
270*250
|
594*594*268
|
16
|
|
GWT550
|
600*600*220
|
550*550*80
|
1000
|
320*200
|
370*250
|
660*660*268
|
17
|
|
GWT610
|
660*660*220
|
610*610*69
|
1000
|
320*250
|
370*300
|
720*720*268
|
18
|
|
GWT820
|
870*650*220
|
820*600*69
|
1300
|
320*250
|
370*300
|
930*710*268
|
20
|
|
GWT630
|
680*680*220
|
630*630*80
|
1500
|
320*250
|
370*300
|
740*740*268
|
22
|
|
GWT726
|
776*534*220
|
726*484*80
|
1200
|
400*200
|
450*250
|
836*594*268
|
22
|
|
GWT915
|
965*660*220
|
915*610*69
|
1500
|
500*250
|
550*300
|
1025*720*268
|
24
|
|
GWT968
|
1018*534*220
|
968*484*80
|
1700
|
500*200
|
550*250
|
1078*594*268
|
32
|
|
GWT1220
|
1270*660*220
|
1220*610*69
|
2000
|
500*200
|
550*250
|
1330*720*268
|
34
|
|
GWT945
|
995*680*220
|
945*630*80
|
2150
|
500*250
|
550*300
|
1055*740*268
|
32
|
|
GWT1260
|
1310*680*220
|
1260*630*80
|
3000
|
600*250
|
650*300
|
1370*740*268
|
37
|
