Large Air Flow V Bank HEPA Filter H13 Galvanized Steel Frame For Clean Room
Price:
negotiable
MOQ:
5
Delivery Time:
Negotiable
Brand:
indair
Product Description
Large Air Flow Galvanized Steel Frame H13 V-Bank HEPA Filter with CE for clean room Low Pressure
Product Description
V-Bank HEPA filter is mainly used to filter airborne particles than 0.3um, made of ultra-fine glass fiber media and hot melt separate folds spacing to ensure best airflow through with minimal resistance, mini-pleated type with high dust holding capacity design, it is the final filtration of air conditioning system, special designed to achieve high winds at low resistance.
Features: High efficiency, large filtration area, big air volume, low resistance, light weight, easy installation, long using life.
Our Advantages:
1. We are the biggest filter manufacturer in China;
2. We are the biggest customer of H&V filter media;
3. There is a state-of-the-art laboratory which enables us to give your customization.
Features: High efficiency, large filtration area, big air volume, low resistance, light weight, easy installation, long using life.
| Efficiency | H13 H14, 99.995% EN:1822 |
| Media | Fiberglass |
| Air filter frame | aluminum alloy/ galvanized sheet |
| Initial resistance | 150pa |
| Final pressure | 600pa |
|
Highest operating temperature |
80ºC |
| Highest humidity | 100% |
| Common size (other size can be customized) |
|
| Application |
|
| Advantages |
|
Application: pre-filter through air filter program, and also
for HEPA filter of the equipments with large air flow
Type: multi-layer V-combined foldaway filter
Final resistance: (suggested) ≤600PA
Temp. resistance: ≤70ºC
Humidity: ≤100%RH
Our Advantages:
1. We are the biggest filter manufacturer in China;
2. We are the biggest customer of H&V filter media;
3. There is a state-of-the-art laboratory which enables us to give your customization.
Hepa filter for cleanroom:
| Model | Width | Height | Depth | Filter elements | Airflow and pressure drop | Efficiency | ||
| (mm) | (mm) | (mm) | (pcs) | (m3/h&pa) | ||||
| WGK610*610*292 (7V) | 610 | 610 | 292 | 14 | 3300/220 | H13 | ||
| WGK610*610*292 (6V) | 610 | 610 | 292 | 12 | 3300/220 | H13 | ||
| WGK610*610*292 (5V) | 610 | 610 | 292 | 10 | 2200/220 | H13 | ||
| WGK610*305*292 (5V) | 610 | 305 | 292 | 10 | 1100/220 | H13 | ||
| WGK305*610*292 (3V) | 305 | 610 | 292 | 6 | 2100/220 | H13 | ||
| WGK592*592*292 (5V) | 592 | 592 | 292 | 10 | 2700/220 | H13 | ||
| WGK592*592*292 (4V) | 592 | 592 | 292 | 8 | 2100/220 | H13 | ||
| WGK592*592*292 (3V) | 592 | 592 | 292 | 6 | 2100/220 | H13 | ||
| WGK592*592*292 (2V) | 592 | 592 | 292 | 4 | 1400/220 | H13 | ||
