Ergonomic Design Smart Air Capture Hood , One - Person Operation Air Flow Hood
Air Capture Hood adopts the pitot principle. It can measure automatically the multi-spots to the wind pressure in many times. Its average amount of wind is correct, fast and simple. It is widely used in mensurating the in-out wind of the air-conditioning and the purification technologie so that the systems can be administered and their parameters are adjusted automatically. It adopts the overseas vanguard technologies of the similar products. Every product will be proofreaded strictly in testing by the multi-spot amount of wind meter before it leaving our factory, in order to providing the reliable guarantee .
Key Features
- Ergonomic design and ultra light weight for easy, one-person operation
- Automatically senses and displays supply or return flows, saving time on the job
- Back pressure compensation ensures accurate readings
- Multiple hood sizes available for easy, cost effective use across multiple jobs
Applications
- HVAC commissioning
- Clean room certification
- Troubleshooting HVAC systems
- Testing and balancing HVAC systems
Included Items
- 610mm x 610mm (2ft x 2ft) air capture hood/frame/base
- Swirl X Flow Conditioner
- Manometer with carrying case
- AA size rechargeable NiMH batteries
- Multi-country AC adapter
- 46cm (18in) Pitot probe
- Static Pressure probes
- 4.8m (16ft) Neoprene tubing
- Wheeled luggage-style carrying case
- NIST traceable calibration certification Downloading software
- USB interface cable
- Manual
|
SPECIFICATIONS FOR AIR FLOW CAPTURE HOOD
|
|||
|
Model
|
ID-ACH-1 air capture hood
|
||
|
Basic Function
|
LCD, Printer Interface, Built-in Batteries can work 30 hours, and No Losing Datas after No Power Source
|
||
|
Measure Range
|
100-3500 m3 /h
|
||
|
Relative Error
|
± 5%F.S
|
||
|
Environmental
|
Temperature :5-35derrees celsius ; Relative Humidity 15%-70%RH ; Prohibit Measuring caustic gas
|
||
|
Standard Accessories
|
1. wind cover 570*570 mm one set 830*830mm one set
2. Battery and Charger one set 3. Optional Equipment Adjustable Bracket one set |
||
