NTSC PAL SECAM RF Signal Detector VS-125 VS-125 5.8GHz Full Band Video Scanner
RF Signal Detector VS-125
VS-1251.2GHz-2.4GHz-5.8GHzFullbandvideoscanner
Description:
This new break through v ideo scanner covers three f requency bands:1.2 GHz-2.4 GHz-5.8 G Hz.The unique5.8GHz scanning technology makes this device the only one of i tskind.
This detector detects and displays multiple hidden wireless cameras in multiple frequency bands up to 300 feet (depending on output powerof source t ransmitter). Itscans 1.2GHz,2.4GHzand5.8GHz three f requency bands synchronously within 30seconds.
This detector has indications of NTSC or PAL / SECAM toidentif y the video system of detected signal. The Stop/ Scan buttoncan latch or release the image. The speaker will display the voice i f there is audio signal with the wireless camera signal.The 3 f requency bands have their own Stop/ Scan but ton and video systemindicator.
This detector has 3AV outputs for recording the video and audio of the 3 f requency bands at the same time.
This is the most advanced hidden wireless camera hunter you are looking for. Specially designed for easy and simple use, which does not require complicated installation or any professional knowledge.
Features:
Unique 5.8 GHz scanning technology.
3.5"High Resolution LCD Monitor, Color or B/W camera compatible.
Video protocol auto- switching for NTSC,PAL/SECAM.
NTSC or PAL/SECAM Video format indication x3 for 3frequency bands.
3 frequency bands auto scanning.
" Fine Tuning" switches for mending screen image.
Scanning LED indic ation x3 for 3 f requency bands synchronous scanning.
3.5 mm Video/Audio output jack x3 for 3bands synchronous
recording.
Specifications:
| Dimension L 19 x H 14 x T 4 cm (antenna length not included) | |
| Weight about 860g (including rechargeable battery) | |
|
Power 1. Switching power adaptor 2. Built-in rechargeable battery |
|
| Battery life About 40 minutes after full charge | |
| Detecting Frequency 1.2GHz, 2.4GHz, 5.8GHz three frequency bands | |
| Monitor 3.5" High resolution LCD, Color or B/W camera compatible | |
| Scan indication 1 NTSC or PAL / SECAM Video format indication | |
| Scan indication 2 Scanning LED indication x 3 for 3 frequency bands | |
|
Warning mode 1. Acoustic display 2. Silent detection through earphone |
|
|
Scanning band 1.2GHz - 2.4GHz - 5.8GHz three bands synchronous scanning |
|
|
Monitor display 1. Auto band switching 2. Band selection switch for manual band change |
|
| Audio Demodulation | 1.2 GHz band 6.0 MHz, 6.5 MHz, 5.5 MHz switable |
| 2.4 GHz band 6.0 MHz, 6.5 MHz, 5.5 MHz switable | |
| 5.8 GHz band 6.0 MHz, 6.5 MHz switable | |
|
Audio / Video output AV outputs x 3 for 3 bands synchronous recording, with 3.5mm Video/Audio output jack x 3 (for recording) |
|
|
Detecting Distance up to 300 feet (depending on output power of source transmitter) |
|
Audio Demodulation:
1.2GHzband: 6.0MHz,6.5MHz,5.5MHzswitable
2.4GHzband: 6.0MHz,6.5MHz,5.5MHzswitable
5.8GHzband: 6.0 MHz, 6.5 MHzswitable
Audio /Videooutput: AV outputs x 3 for 3 bands synchronousrecording,
with 3.5mm Video/Audio output jack x 3 (for recording)
Detecting Distance: up to 300 feet (depending on output power ofsource
transmitter)
The detecting distance will be varied depending on the type and output power of signal sources.
