China 12kv Outdoor MV Voltage Transformer Single Phrase 50 / 60hz for sale

12kv Outdoor MV Voltage Transformer Single Phrase 50 / 60hz

Price Negotiable
Price: Negotiable
MOQ: 1set
Delivery Time: Negotiable
Brand: Chuangyin
Product Description

12kv Outdoor Single-Phrase Epoxy Resin Type







1. Product Introduction:







2. Technical Data:



1 Installation site:  Outdoor

2 Rated Frequency: 50/60hz

3 Burden Power Factor :  cosθ=0.8(lagging)

4 Technical Standard Accords with IEC60044-2    IEC61869-1&3







3. Specificaton





Rated Primary Voltage

(kV)



Rated secondary

Voltage

(kV)

 Accuracy classes combination

Rated output

(VA)

Thermal limiting output

(VA)

 Rated insulation level(kV)
Three-phase Zero-sequence
11/ 0.11/ 0.11 0.2/3P 75/100 1200 12/28/75
0.5/3P 150/100
1/3P 300/100
0.11/ 0.11 0.2/0.2/6P(3P) 45/45/1000
0.2/0.5/6P(3P) 45/75/100
0.5/0.5/6P(3P) 90/90/100


4.Outline Drawing

















5.Photos
