3.0 - 5.0mm Zeolite Molecular Sieve Adsorbent For High Voltage Electric Equipment Switchgear
3.0 - 5.0mm KDH-03 Zeolite Molecular Sieve Adsorbent For High Voltage Electric Equipment Switchgear
Product Description of Molecular Sieve Adsorbent
The leading products of Xi'an Lvneng Purification Technology Co., Ltd.
include F-03 and improved KDHF-03. As special absorbents for high-voltage substation equipments,
their quality has reached and even surpassed that of the Japanese competing products.
Therefore, they have not only been widely used in domestic high voltage electrical products and equipments, but for export, and are quite popular among users.
Technical Specification of Molecular Sieve Adsorbent
| Model | KDHF-03 | |
| Diameter (mm) | Φ2-3 | φ4-6 |
| Loss on Ignition (wt%.575℃, 1hr) | ≤ 1.0 | ≤ 1.0 |
| Bulk density (g/ml) | ≥ 0.7 | ≥ 0.68 |
| Crushing strength (N) | ≥ 60/particle | ≥ 120/particle |
| Static H2O capacity (wt%) | ≥ 23 | ≥ 23 |
| Attrition rate (wt%) | ≤ 0.3 | ≤ 0.3 |
| Particle qualification (%) | ≥ 98 | ≥ 98 |
| Package moisture content (%) | ≤ 1.0 | ≤ 1.0 |
| Decomposer | Equilibrium Adsorption(ml/g) |
| S2F10O | ≥0.76 |
| SO2 | ≥10.8 |
| SOF2 | ≥6.7 |
Application of Molecular Sieve Adsorbent
1100kV Gas insulated Metal Enclosed Switchgear (GIS)
SF6 Generator Circuit Breaker complete set (GCB)
Rigid gas insulated transmission line (GIL)
etc.
Package of Molecular Sieve Adsorbent
Factory View of Molecular Sieve Adsorbent
Attention of Molecular Sieve Adsorbent
- The product cannot be exposed in the open air & should be stored in dry condition with air-proof bag.
- It should be regenerated after a certain period of adsorption. The appropriate regenerated temperature would be better below 350°C.
FAQ of Molecular Sieve Adsorbent
Q: Could we send a free sample for reference?
A: Yes, of course.
Q: What about the price and MOQ?
A: We promise a competitive price with top quality, & accept both mass and small quantity order.
Q: What is the lead time?
A: Within 15 days after received payment.
Q: Payment term?
A: 100% TT in advance. or 30% TT deposit & balance before shipment.
Q: How to solve problems after sales?
A: Take photos of the problems. After confirmed, we will make a satisfying solution for you within 3 days.
For more information please contact us. It's our pleasure to serve you.
