SMD3030 DC24V IP68 170ma Waterproof Circular Led Underwater
DC24V IP68 Structural waterproof led Underwater swimming pool lights
Specification
| Model | HG-UL-3W-R-SMD | |
| Electrical | Voltage | DC24V |
| Current | 170ma | |
| Wattage | 3±1W | |
| Optical | LED chip | SMD3030LED(CREE) |
| LED (PCS) | 4PCS | |
| Certification | FCC,CE, RoHS, IP68, IK10 | |
| LUMEN | 300LM±10％ |
certification
Product features
1. Multiple wattage options from 3W-48W.
2. Swimming pool light led get UL certification.
3. Structure waterproof stainless steel lamp cup.
Application
led swimming pool light widely used in swimming pools, Plastic film pools, glass
fiber pools,Bath pools,hot spring pools and other underwater lighting.
Packing List
| Packing/ Shipping | Lamp sizeInner box dimension |
104×104×133mm |
||||||
| N.W. / pc |
475g |
|||||||
| G.W. / pc |
525g |
|||||||
| Carton dimension |
540×540×285mm |
|||||||
| Qty. / ctn. |
50PCS/CTN |
|||||||
| G.W. / ctn. |
27.5Kg |
All passed 30 steps quality control , 100% waterproof at 10m depth, 8 hours LED agening test,
100% inspection before deliver.
Heguang LED pool lighting exhibition
FAQ
Q1: How to choose the right LED energy saving lamps?
Low watage with high Lumen. This will save more electricity bill.
Q2: What is the advantages of LED?
Environmental friendly, Energy saving and Long lifespan.
Q3: The key factor that influence LED lifespan.
Temperature: It requires that junction temperature of LED chip should be ≤120℃, so the center
temperature at the LED bottom of light board should be ≤ 80 ℃.
