SS316L 850LM Outdoor Garden Inground Light 100-240V 6500K Par56 Pool Light

Price Negotiable
Price: negotiation
MOQ: 1 pcs
Delivery Time: 7-10 working days
Brand: Birmate
Product Description

Product Features

1. VDE standard rubber wire, connected with IP68 nickel-plated copper connector.

2. IP68 Structure waterproof, all products succeeded in 10m deep water testing before delivery.

3. Lamp succeeded in the IES and Temperature rise test

4. Integrated bead lens with uniform lighting ,no dazzling,light transmittance >85%

5. Customized IP68 waterproof nickel plated brass design,good anti-corrosion.



Specification

HG-UL-9W-SMD-G2-H

Lamp parameter Material SS316L body+tempered glass cover+VDE rubber cable
length 150×150×87.5mm
Input voltage A100-C240V
Constant Driver yes
Over-current Protection yes
Wattage 9±1W CREE
Light lumen 850LM±10%
Beam angle 15°/30°/45°/60°
CCT

Pure White: 6500±10%

Warm White:3000K±10% costomized

Specifics Operating Temperature (℃) -20~40℃
IP Rating IP68
Certificate CE, RoHS,FCC,IP68,IK10
Life-span 50,000 hours
Warranty 2Years
Test position LED Grond light (Min)
Working temperature 28℃ Working temperature 40℃
land test (Min) 480 480
LED edge temperature(℃) 68 75





Advantage

1. Reliable quality with 100% 10m depth waterproof test.

2. In ground pool light must be 8 hours aging test.

3. Warm white ground lights Finished products all passed 30 steps quality inspection

4. IP68 structure waterproof, can long time use underwater.

5. Constant current driver, comply with CE & EMC standard.



Application

mini ground light wdely used as garden, community, lawn, park and other landscape lighting



Some tips for you

1. All lamps are self-developed patent products.

2. According to the LED characteristic, the center temperature at the LED bottom of light board

must be controlled strictly( ≤ 80 ℃).

3. High quality driver of lamps to ensure the long lifespan.

4. All products have passed CE, ROHS, FCC, IP68, and our Par56 pool light have got UL certification.

5. All products need to pass 30 steps QC inspection, the quality has the guarantee, and the faulty rate

is less than three per thousand.

6.Low watage with high Lumen. This will save more electricity bill.
