Intelligent Program Wall Hung Gas Boiler For Heating And Shower
Energy Saving Wall Hung Gas Boiler With Function Of Intelligent Program For Heating And Shower
Technical data
| Model Number | LIPB20 | L1PB24 | L1PB28 |
| Gas Type | NG/LPG | ||
| Rated Gas Pressure(Pa) | 1300/2000/2800 | ||
| Efficiency Under Rated Heat Input(%) | Above88% | ||
| Rated Gas Input(kw) | 20 | 24 | 28 |
| Rated Gas Output(kw) | 17.6 | 21.1 | 24.7 |
| Electric Power(W) | 110 | 110 | 110 |
| Temp.Range Of Heating Water(℃) | Radiator:30-80 Floor Heating:30-60 | ||
| Heating Area(㎡) | 80-160 | 100-200 | 160-260 |
| Lift Of pump(m) | 5 | 5 | 6 |
| Application Water Pressure(Mpa) | 0.1-0.3 | ||
| Preset Pressure Of Expansion Vessel(Mpa) | 0.1 | ||
| Water Circulation Type | Airtight Forced Circulation | ||
| △T=25℃ Hot Water Supply(kg/min) | 10 | 12 | 14 |
| △T=30℃ Hot Water Supply(kg/min) | 8.3 | 10 | 11.7 |
| Temp.Range Of DHW Supply(℃) | 30-60 | ||
| Applicative Water Pressure(mpa) | 0.03-0.8 | ||
| The Minimum Starting Flow (L/min) | 2 | ||
| The Minimum Closed Flow(L/min) | 1.6 | ||
| Connections(mm) |
For Gas&Heating Water Pipes:G3/4 For DHW Pipes:G1/2 |
||
| Air Input/Exhaust Duct(mm) | φ60/φ100 | ||
| Sparated Input/Exhaust Duct(optional) | φ80/φ100 | ||
| The length Of Flue Dust(m) | 1 | ||
| Noise On Working(DB) | ＜42 | ||
| Exhaust Type | Forced Exhaust | ||
| Ignition Type | Integrated Automatic Ignition | ||
| Temperature Control | Gas Proportional Adjustment | ||
| Product size(mm) | 740*400*305 | 740*430*320 | |
| Packing size(mm) | 855*470*390 | 860*500*395 | |
| Container(20GP/40GP/40HQ) | 166/333/404 | 135/310/380 | |
- Various capacity available. Input capacity(20kw,24kw,28kw,32kw) can match with different house type.
- Automatic electronic ignition and ionization flame control.
- Protected service menu for internal functions and working parameters adjusting.
- Supports smooth control with Open Therm room thermostat from any producer.
- The invention patent high-frequency electronic anti scaling device and the original windbreak and sand structure design are
committed to manufacturing gas wall hanging stove products suitable for our conditions.
- With normal mode, state mode, diagnostic mode, failure mode, can quickly provide comfortable hot water in a very short time.
- Integrated pump, expansion tank, heating safety valve,manometer,automatic air exhaust device.
- Stable appearance,classic style, simple and handsome-one shell.
- Large LCD blue screen, so that the boiler running at a glance.
- With efficient, energy saving and high lift water pump ensure boiler low water supplier reliable and comfortable.
- Advanced pressure sensors technology process monitoring and water pressure displaying, ensure boiler safety.
- Room sealed combustion chamber with strengthened micro-negative pressure technology, avoiding any leakage of exhaust gas.
- The unique anti-corrosion coating and condensing water treatment technology, extend effectively the using life-time of the boiler.
- Proportional controlling of gas flow, and heating with frequency conversion.
- With design of stable wind resistance, and the boiler works stably even in bad weather.
- With Aluminum fan and good quality ball bearing ensure low noise while working.
- The main parts are come from famous brand supplier which ensure best quality.
- The main parts are come from famous brand supplier which ensure best quality.
- Unique remote control system realizing climate compensation function,ensure energy saving.
- High flow hot water central supply system,able to provide multiple users with hot water simultaneously.
