Plastic Switch Socket Parts PPSN LED Enclosure Injection Tooling
Price:
negotiable
MOQ:
1000 pieces
Delivery Time:
15-40days
Brand:
OEM/ODM
Product Description
Plastic switch or socket parts LED enclosure injection tooling home plastic injection molding
Mould Information:
| Mold information | content |
| Product Material | ABS,PP,PC,PA,PMMA,PS,POM and etc. |
| Moldbase | FUTABA, LKM, HASCO, DME you can choose |
| Cavity material | 45#,50#,P20,H13, 718 2738, NAK80, S136, SKD61 etc |
| Runner | Cold/Hot runner |
| Cavity | Multi or single cavity |
| Standard parts | Hasco |
| Gate type | Side gate, Sub gate, Pin-point gate, Edge gate, etc |
| Treatment | Heat treatment and Nitriding, polish, etc. |
| HRC | H45~52 |
| Product weight | 50~5000 K |
| Machine type | 250Ton |
| The standard of appearance of the products for stripe | MT(Mold Tech), YS, HN series |
| The way of Color contrast | RAL K7, PANTONE |
| Plastic Mold (Moulds) production process | Description |
| 1. 3d Design/Samples for quotation | According to 3D drawing or samples for quotation. |
| 2 Negotiations | Including the price of molds, molds sizes, material for cores & cavities, weight of the product, part cost, payment, molds lifetime, delivery, etc. |
| 3. Purchasing Order | After the customer confirming the mold design and quotation. |
| 4. Making mold(mould) | Confirm drawing, start to do DFM, mold flows and mold detail agreed with the customer, start production. |
| 5. Production schedule | Every week we will feedback to the customer mold progress(picture). |
| 6. sample shoot | We provide the molds test samples for confirmation(about 10-15 pieces), then, get your signature sample, mass production. |
| 7. Package | Wooden case for molds, cartons for parts, or as your requirement. |
| 8. Delivery | Delivery goods by air or by sea. |
Our Services
| Processing capacity: | Mold design, mold making and plastic injection molding |
| Material of Mould | 45#, P20, 718, 718H, 2738, 2316, S136 and more kinds of material you can choose, |
| Mould frame: | 45Pre-hardened>30 HRC |
| Cooling System: | Recirculating |
| Medium-term treatment: | Tone quality, improve the hardness |
| Post-processing: | Nitride(Nitriding temperature is low, deformation is small, it is no longer the need for quenching high surface hardness(over HV850) and wear |
| Die life: | P20 Normal use no less than 30 million times |
| Molding process technology | Review plan--- Stock preparation--- Processing-- Rough mold base --- Punch machining--- EDM die sinking--- Die Machining---Inspection--- Assembly--- Flight mode--- Tryout--- Customer confirm the sample--- producer of delivery to the customer |
| Transportation: | In the mold must be installed before shipment clamping piece, packing strong, rust-proof, logistics and transport |
| After-sales service: | Die 1-year repair, Free maintenance during warranty |
| Note | Mold in the production process, we provide information each week and take pictures. |
| Runner system | 1 point gate hot runner |
| Ejection system | Inclined ejecting block |
| Molds running | Full automaticity |
| Molds features | Complex mold structure. etc. |
| Injection cycle time: | 12s, 15s, 18s, 20s, 22s, 25s(high speed injection machine) |
| Cavity | Single/multifunctional |
| Runner | Hot/Cold |
| Design software | UG,PROE,CAD,CAXA,ETC |
| Mould life | 30000-500000 Shots |
| Delivery time | 15-60days |
FAQ
Q: Can you accept OEM service?
A: Yes, we are warmly welcome OEM service. Just send your 2D&3D drawing or golden sample with quality demand (such as material, surface treatment, color, and package) to us.
A: Yes, we are warmly welcome OEM service. Just send your 2D&3D drawing or golden sample with quality demand (such as material, surface treatment, color, and package) to us.
Q: What is the drawing format you needed?
A: Prefer to STP, DXF for 2D&3D drawing, and PDF, AI, CDR, JPG for artwork design.
A: Prefer to STP, DXF for 2D&3D drawing, and PDF, AI, CDR, JPG for artwork design.
Q: What is your MOQ?
A: Usually our MOQ is 1000pcs, but we accept lower volume for your trial order.
A: Usually our MOQ is 1000pcs, but we accept lower volume for your trial order.
Q: Can I get samples?
A: Sure, we usually provide a free store sample to you for quality checking. 1~2days can delivery. But there is a little sample fee that would be charged if you request your OEM samples, and it is refundable when your order is up to a certain quantity. 3~5days can delivery.
A: Sure, we usually provide a free store sample to you for quality checking. 1~2days can delivery. But there is a little sample fee that would be charged if you request your OEM samples, and it is refundable when your order is up to a certain quantity. 3~5days can delivery.
Q: How much is the freight charge?
A: To save money and time, we suggest to deliver by express for small quantity, and deliver by sea for large quantity. At the same time, we can get a big discount from a shipping company.
A: To save money and time, we suggest to deliver by express for small quantity, and deliver by sea for large quantity. At the same time, we can get a big discount from a shipping company.
Q: Do you have a quality guarantee?
A: Yes. We have a QC department and 100% inspection before shipping, to ensure the CNC parts is NO visual defects, a traceable quality record for the product shipped from us.
A: Yes. We have a QC department and 100% inspection before shipping, to ensure the CNC parts is NO visual defects, a traceable quality record for the product shipped from us.
