HOWO Truck 6X4 Dump Truck Sinotruk Tipper 10 Wheel 50 Tons Tractor Truck
Price:
Negotiation
MOQ:
1 unit
Delivery Time:
30-45 work days
Brand:
sinotruk
Product Description
-
What are your payment terms? We primarily accept T/T (30% advance payment with the balance due before shipping) and L/C. However, please feel free to contact us if you prefer alternative payment arrangements.
-
What is the delivery time? For the HOWO 371 truck head, we will arrange shipment within 40 days after receiving the advance payment.
-
How long is the warranty period? We provide a one-year warranty for the truck.
-
How do you support after-sales service? We offer lifelong after-sales support. Our engineers are available for overseas training, and spare parts will be dispatched as quickly as possible.
| Truck Brand | SINOTRUK—STW | ||
| Dimension(Lx W xH)(unloaded)(mm) | 6800*2496*3668 | ||
| Approaching angle/Departure angle(°) | 16/70 | ||
| Overhang(front/rear) (mm) | 1500/725 | ||
| Wheel base (mm) | 3200+1400 | ||
| Max speed(km/h) | 102 | ||
| Curb weight(kg) | 9210 | ||
| Loading Weight(kg) | 39200 | ||
|
Engine (Steyr technology, made in China) |
Model | WD615.96E,4 stroke direct injection diesel engine, 6-Cylinder in-line with water cooling, turbo-charger and inter-cooling | |
| Engine Type | common rail electronic computer controlled | ||
| Fuel type | Diesel | ||
| Horse Power, max(kw/rpm) |
371hp |
||
| Emission | EURO II | ||
| Fuel tanker capacity (L) | 400L | ||
| Brake system | Service brake | Dual circuit compressed air brake | |
| Parking brake | spring energy, compressed air operating on rear wheel | ||
| Auxiliary brake | Engine exhaust brake | ||
| Steering system | Model | ZF8098 hydraulic steering with power assistance | |
| Front axle | HF7 with disc brake | ||
| Rear axle | HW16 double driving axle, the HOWO driving axle is one of the biggest single reducer axles among the world, strong enough to bear big loading capacity, easy to get maintenance, Ratio: 4.22(ST16,HC16,AC16) | ||
| Color | Optional | ||
| Tire | 295/80R22.5 tubeless tire | ||
| Tire Quantity | 10+1 spare | ||
| Fifth wheel | 50mm | ||
| Electrical system | Battery | 2X12V/165Ah | |
| Alternator | 28V-1500kw | ||
| Starter | 7.5Kw/24V | ||
-
Regular follow-ups to monitor the performance of the tipper truck and provide technical recommendations.
-
Prompt supply of spare parts to ensure continuous operation of the HOWO 371 truck head.
-
Our overseas engineers are always on standby to provide assistance.
