Sinotruk HOWO 8*4 Fuel Tank Truck 12 Wheels Oil Tanker 30000L Dispenser Truck
Price:
Negotiation
MOQ:
1 unit
Delivery Time:
30-45 work days
Brand:
sinotruk
Product Description
Sinotruk HOWO 8*4 Fuel Tank Truck 12 Wheels Oil Tanker 30000L Dispenser Truck
Product Description
Product Description
-
The HOWO truck incorporates cutting-edge international technologies for heavy-duty vehicles, developed by Sinotruk to meet global technical standards. Designed with reliable performance and competitive pricing, HOWO trucks are engineered to enhance operational efficiency and deliver profitability for customers.
-
Equipped with engines ranging from 260 to 420 horsepower, the HOWO truck meets Euro II emissions standards, offering robust power output while maintaining low maintenance costs.
-
Featuring a next-generation transmission system specifically designed for heavy-duty applications, the primary transmission utilizes a twin-countershaft structure, while the auxiliary transmission employs a planetary reduction design. This configuration ensures superior load-bearing capacity and enhanced reliability.
-
The truck is equipped with a 16-ton rear axle and a 9-ton front axle, delivering higher rigidity and load capacity. With a long service life, low noise levels, and customizable gear ratios, the design is tailored to meet diverse operational requirements.
-
All chassis and cab components are manufactured using robotic technology and feature an integrated steel-framed structure. This construction ensures exceptional durability, high collision resistance, and superior protection against external forces, prioritizing driver safety.
-
Sinotruk maintains long-term partnerships with renowned international automotive component suppliers, ensuring uncompromising quality in every aspect of the product.
-
As China’s leading manufacturer and exporter of heavy-duty trucks, Sinotruk has exported over 350,000 vehicles globally. With more than 500 service and distribution networks, customers enjoy easy access to spare parts and reliable after-sales support.
| Vehicle Model: | ZZ1317V4667N1 | |
| Overall Dimension(L x W x H) | 11900×2500×3450(mm) | |
| Wheelbase: | 1800+4600+1400mm | |
| Curb weight: | 11250kg | |
| Drive Type: | 8x4 | |
| Engine | Model | D12.42 ,420HP, Euro 2 |
| Type | 6-cylinder in line, water-cooled,4-stroke,turbocharged & inter-cooled, high pressure common rail | |
| Displacement(ml) | 11596 | |
| Number of cylinder | 6 | |
| Max.power(HP/rpm) | 420HP(309kw) | |
| Max.torque(N.m/rpm) | 1820N.m/1100-1400 rpm | |
| Transmission | HW19712 transmisson, 12 forward and 2 reverse | |
| Front axle | HF9 | |
| Driving axle | HC16 | |
| Cabin | T7H front face, with A/C, with double sleeper | |
| Front Wheel Tread: | 2022/2022, 2041/2041mm | |
| Rear Wheel Tread: | 1830/1830mm | |
| Tire Model: | 295/80R22.5 with one spare tire | |
| ABS | No | |
| Fuel Tank | 400L | |
| Tank body specs | Tank volume | 30,000L |
| Tank material | Aluminum alloy | |
| Compartments | 8 Units: 2000L/2000L/2000L/4000L /4000L/4000L/6000L/6000L(can be customized) | |
| Manhole | 8 Units, 3 units 16"Aluminum alloy 5 units 20" Aluminum alloy |
|
| Foot Valves | 8 Units, 4"Aluminum alloy, pneumatic operate | |
| Discharge ball valves | 8 Units, 2.5"Aluminum alloy | |
| Pump in and Pump Out | Equipped | |
| Ladder: | A detachable carbon steel ladder is equipped at the front of the tank | |
| Handrail | Stainless steel pneumatic handrail at both sides on the top of tank | |
| Gauge | Equipped, 1pcs each compartment | |
| Calibration | Without | |
| Tool box | 1pcs | |
