New 42ton 6*4 375HP Wide-body Mining Dump Truck TL855B Nowa Gold Mine Dump Truck

New 42ton 6*4 375HP Wide-body Mining Dump Truck TL855B in Stock Nowa Gold Mine Dump Truck

Mining Truck Product Description

1. Heavy-Duty Performance:
   • Built to operate under extreme working conditions, ensuring reliability and durability.
2. Advanced Plate Spring Structure:
   • Features a newly designed plate spring structure for enhanced load-bearing capacity.
3. Economical Design:
   • Engineered to meet industry standards with optimized operational efficiency and cost-effectiveness.
4. Field-Specific Optimization:
   • Tailored for diverse applications, ensuring strong regional adaptability and versatility.
5. High Transport Efficiency:
   • Under standard operating conditions, the single-trip transport capacity exceeds 60 tons, with an operational attendance rate of over 85%, delivering exceptional productivity.
6. Enhanced Load-Bearing Capacity:
   • Equipped with a 20-ton front axle and 35-ton mid-rear axle, combined with a scientifically designed suspension system, significantly improving the overall load-bearing capacity of the vehicle.
7. Safety & Reliability:
   • Features an intelligent IBS auxiliary braking system, dual steering gear system, and advanced safety defense mechanisms to ensure vehicle safety in all operational conditions.
8. Proven Technology & Performance:
   • Backed by mature technology and stable performance, this truck offers low acquisition costs and high operational efficiency. Its load-bearing capacity is 30% higher compared to road vehicles of the same power.

Whether for mining, construction, or other demanding applications, this mining truck combines power, efficiency, and reliability to deliver outstanding performance.

Vehicle Brand		SHAANXI TONLY
Vehicle Model		TL855B
Cab		Single narrow body cab with A/C ( Left Hand Cabin)
Body paint color		Engineering yellow
Whole Vehicle main Dimensions	Overall dimensions (LxWxH)mm	8850×3200×3520
	specification of bucket	capacity of bucket :25M3; Bottom plate 16mm and side plate 10mm, high strength plate. with tailgate
	Lifting System	Type: HY VA ,the angle of hoist:51±2°
	Wheel base	3600+1500
	Driving type	6×4
Weight Data	(kg)Curb weight	23000
	(kg)Rated payload	40000
	Persons in cab	1
	GVW(kg)	63000
Main Performance	Middle and ear axle	25T+25T HA NDE double hub reducer cast steel axle,
	Front axle	13T HA NDE axle, integral welding structure front axle
	Transmission (MT)	FA ST 7DS180 (7 forward gears,1 reverse gear)
	Steering system	Double turning system
	Clutch	E-aton Clutch
Engine	Model	Wei Chai : WD12G375E211
	Type	Inline, six-cylinder, four-stroke water-cooled direct injectors turbo-charged diesel engine
	Displacement(L)	12L
	HP	375
Fuel tank (L)		400
Wheels and tyre size		10+1/14.00-25-36PR
		Engineering tyre
attachments		back bumper stone clean device fuel tank protection grill reverse hooter stop block spare tyre protector
