Sinotruk HOWO 6X4 Sewage or Fecal Suction Truck Delivery Truck Transport Truck Cargo Truck
Sinotruk HOWO 6X4 Sewage or Fecal Suction Truck Delivery Truck Transport Truck Cargo Truck
The HOWO Sewage Truck, often referred to as a sewage suction truck or septic tank truck, is a specialized heavy-duty vehicle. It's manufactured by Sinotruk, a prominent Chinese automaker known for producing strong and reliable commercial vehicles. This truck is designed for efficiently collecting, transporting, and disposing of sewage, wastewater, and other liquid waste from places like sewage treatment plants, industrial sites, construction areas, and residential zones. With its sturdy construction, powerful performance, and safety features, the HOWO Sewage Truck is a trusted choice for municipal bodies, waste management firms, and industrial businesses around the globe
| Sewage Suction Vacuum Truck Technical Specification | ||
| Product Name | Sino howo SEWAGE SUCTION TRUCK |
|
| Chassis Model | ZZ1250 | |
| Fuel type | Diesel | |
| Emission Standard | Euro 2 | |
| Cabin | HW16 | |
| Whole Vehicle main dimensions (mm) |
Overall dimensions (LxWxH) | 9500*2400*3300 |
| Wheel base | optional | |
| Min. ground clearance | 480 | |
| Weight data (kg) | G.V.W | 25000 |
| Curb weight | 1200 | |
| Max payload | 16000 | |
| Whole vehicle main performance |
Max. speed (km/h) | 95 |
| Max. slope of climb (%) | 30 | |
| Engine |
Model | WD615 47 |
| Maximum power | 336HP | |
| Number of cylinders | 6 | |
| Displacement (ml) | 9.726 | |
| Gear box | Model | 9 |
| Number of gears | 9 forward gears &1 reverse | |
| Axle | Front Load capacity (ton) | 7 |
| Rear Load capacity (ton) | 18 | |
| Steering Wheel | left/right hand drive | LHD,RHD |
| Brake system | Service brake | Air braking |
| Electric device | Rated voltage | 24V |
| Tyres&Quantity | 10.00-20& 6+1 | |
| Sewage Suction Vacuum Truck Special Tank Description | ||
| Tank |
Material:high quality carbon steel Structure:welding,vacuum tank,Cylindrical |
|
| capacity(L) | 16000 | |
| thickness of material | 6mm | |
| pump |
type | vacuum pump |
| model | 65QZ-40/45N | |
| flux(L/S) | 65 | |
| rating speed(r/min) | 500 | |
| shaft power(kw) | 4 | |
| features | Low speed,low fuel consumption,low noise,high vacuum,high efficiency | |
| manufacture | Hangzhou Weilong Pump Co.,Ltd,(Famous in China) | |
| pipe | 65-100mm suction and discharge pipe | |
| special function | suction time ≤ 5min, effective suction range ≥ 8, max vacuum degree ≤ 15 Kpa, dump angle ≥ 45 |
|
| equipment | Equipped with power take off,transmission shaft,fecal tank, pipe network,fecal pipe for observing and cleanout equipment Time for full suction less than 5min |
|
| hydraulic lift and lock discharge cover. sewage tube,vacuum pump,recovery,etc | ||
