HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck
Price:
Negotiate
MOQ:
1 unit
Delivery Time:
40 worker days
Brand:
SINOTRUK
Product Description
HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck
Product Description
HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck
1. Fecal Suction Truck Vacuum Tank Truck
1.1 vacuum tank sewage suction truck is loading and discharging quickly.
1.2. Fecal suction truck with 16cbm tank volume.
1.3. Sewage suction truck is discharged clearly.
2. Fecal Suction Truck Vacuum Tank Truck main equipment:
sewage suction tank truck cab - single and half row, optional: A/C
vacuum sewage truck Engine - sino howo, 6 cylinders
vacuum truck manual gearbox -9-speed
sewage truck drive axle loading capacity- 20T
vacuum suction truck tire - 10.00-R20
vacuum sewage sucking truck tank capacity - 16cbm
3. Fecal Suction Truck Vacuum Tank Truck main specification:
1. Fecal Suction Truck Vacuum Tank Truck
1.1 vacuum tank sewage suction truck is loading and discharging quickly.
1.2. Fecal suction truck with 16cbm tank volume.
1.3. Sewage suction truck is discharged clearly.
2. Fecal Suction Truck Vacuum Tank Truck main equipment:
sewage suction tank truck cab - single and half row, optional: A/C
vacuum sewage truck Engine - sino howo, 6 cylinders
vacuum truck manual gearbox -9-speed
sewage truck drive axle loading capacity- 20T
vacuum suction truck tire - 10.00-R20
vacuum sewage sucking truck tank capacity - 16cbm
3. Fecal Suction Truck Vacuum Tank Truck main specification:
| Sewage Suction Vacuum Truck Technical Specification | ||
| Product Name | Sino howo SEWAGE SUCTION TRUCK |
|
| Chassis Model | ZZ1250 | |
| Fuel type | Diesel | |
| Emission Standard | Euro 2 | |
| Cabin | HW16 | |
| Whole Vehicle main dimensions (mm) |
Overall dimensions (LxWxH) | 9500*2400*3300 |
| Wheel base | optional | |
| Min. ground clearance | 480 | |
| Weight data (kg) | G.V.W | 25000 |
| Curb weight | 1200 | |
| Max payload | 16000 | |
| Whole vehicle main performance |
Max. speed (km/h) | 95 |
| Max. slope of climb (%) | 30 | |
| Engine |
Model | WD615 47 |
| Maximum power | 336HP | |
| Number of cylinders | 6 | |
| Displacement (ml) | 9.726 | |
| Gear box | Model | 9 |
| Number of gears | 9 forward gears &1 reverse | |
| Axle | Front Load capacity (ton) | 7 |
| Rear Load capacity (ton) | 18 | |
| Steering Wheel | left/right hand drive | LHD,RHD |
| Brake system | Service brake | Air braking |
| Electric device | Rated voltage | 24V |
| Tyres&Quantity | 10.00-20& 6+1 | |
| Sewage Suction Vacuum Truck Special Tank Description | ||
| Tank |
Material:high quality carbon steel Structure:welding,vacuum tank,Cylindrical |
|
| capacity(L) | 16000 | |
| thickness of material | 6mm | |
| pump |
type | vacuum pump |
| model | 65QZ-40/45N | |
| flux(L/S) | 65 | |
| rating speed(r/min) | 500 | |
| shaft power(kw) | 4 | |
| features | Low speed,low fuel consumption,low noise,high vacuum,high efficiency | |
| manufacture | Hangzhou Weilong Pump Co.,Ltd,(Famous in China) | |
| pipe | 65-100mm suction and discharge pipe | |
| special function | suction time ≤ 5min, effective suction range ≥ 8, max vacuum degree ≤ 15 Kpa, dump angle ≥ 45 |
|
| equipment | Equipped with power take off,transmission shaft,fecal tank, pipe network,fecal pipe for observing and cleanout equipment Time for full suction less than 5min |
|
| hydraulic lift and lock discharge cover. sewage tube,vacuum pump,recovery,etc | ||
