Concrete Mixer Truck

8×4 371 HP Euro II Cement Mixing Equipment , Truck Mounted Concrete Mixer With HW76 Cab

Price Negotiable
Price: Negotiable
MOQ: 1 UNIT
Delivery Time: 30-45 work days
Brand: HOWO
Product Description

HOWO 8×4 371 HP Euro II Concrete Mixer Truck with Optional color and HW76 Cab



Description:



SINOTRUK HOWO 8×4 Concrete mixer truck  the satisfied product with high level standard.

and the full aspect service from order to shipping.We can give customer most suitable advice when customer has special needs for your transportation or construction,the output torque automatically according to loads change.And we are specialized in this area more than 10 years,rich experience and well after-sale service.In the last,technique support and training. Customization service, as per your request, we will customize our production



Packing:



The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.And we have rich packing experience and well service.



Competitive Advantage:



1.Adopt HW76 Cab single bunk,new type seat,adjustable steering wheel

2.EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.

3.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.

4.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.

5.Rich experience and well after-sale service.



Engine
Engine Model WD615.47
Fuel Type Diesel
Cylinders 6
Max Power 276kw
Max Horsepower 371hp
Displacement 9.726L
Emission Standard Euro II
Engine Type Straight Line
Chassis Type HOWO
Rear Axle Speed Ratio 5.73
Tire Number 12
Tyre Size 11.00R20
Tread Front Tread: 2041/2041mm;Rear Tread: 1830/1830mm
Clutch Φ 430
Steering Machine ZF8118
Brakes

Service brake: Dual circuit pneumatic brake;

Parking brake: Spring energy, compressed air operating on rear wheels;

Auxiliary brake: Engine exhaust brake

Electrics

Operating voltage:24V,negative grounded

24V,7.5KW.Starter:24V,7.5 Kw

28V,1500W.Alternator:3-phase,28V,1500 W

Batteries:2x12 V,165 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light

Basic Parameter
Driving Mode 8*4
Vehicle Dimensions 10175×2496×3125
Front Suspension/Rear Suspension 1500/1460 mm
Wheelbase 1800 + 3600+1350 mm
Curb Weight 11250kg
Gross of Weight 31000kg
Max. Speed 80km/h
Parameters
Vehicle Announcement ZZ1317N3667A
Vehicle Type Concrete Mixer Truck
