SINOTRUK Euro II Heavy Duty Dump Truck 6x4 U Shape Cargo Body 18m3 Capacity
SINOTRUK 6x4 18m3 Euro II DUMP TRUCK With U-type cargo body and orange color
Description:
This model adopt HW76 Cab single bunk,new type seat,adjustable steering wheel.EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.
Competitive Advantage:
1. Professional Sales Team of trucks. Our target is not selling trucks; we help customers choose the best suitable trucks as per customer’s situation.
2. Professional team for spare parts and aftersales services.
3. Technique support and training.
4. Customization service, as per your request, we will customize our production for you
5. Warranty: one year or 10000 km
6. Production time: within 35 working days
| Main Specification | |||
| Model | ZZ3257N3447A | ||
| Condition | New | ||
| Drive type | 6×4 | ||
| Brand | HOWO Dump Truck | ||
| Steering Wheel Type | LHD(Left hand drive) (RHD is in option) | ||
| Overall Dimension(mm) | 7835×2496×3170 | ||
| The total mass(Kg) | 25000 | ||
| Kerb weight(kg) | 12390 | ||
| Wheel base(mm) | 3425+1350 | ||
| Dimension of cargo body(mm) | L×W×H | 5200×2300×1500 | |
| Thickness of steel plate | Bottom: 8mm Side:6mm | ||
| Capacity | 18m3 | ||
| Tipping system | HYVA Front tipping system | ||
| Fuel Type | Diesel | ||
| Engine | Type |
SINOTRUK brand,WD615.47 Inline six-cylinder, water-cooled, four-stroke, turbocharged inter-cooled Direct injection |
|
| Emission standard | EURO II | ||
| Horse power | 371hp | ||
| Maximum output | 273Kw @ 2200 rpm | ||
| maximum torque | 1500N.m | ||
| Displacement(L) | 9.726 | ||
| Cabin | HW76 Cabin with two seats, and one sleeper, air conditioner, | ||
| Steering | German hydraulic steering with power assistance | ||
| Transmission | Manual Type. HW19710 Sinotruk 10 Speed Transmission,10 forward and 2 reverse | ||
| Clutch | Ø430mm dry diaphragm spring diameter clutch Hydraulic boosting | ||
| Front axle | HF9(9 ton), plate (disc) brake | ||
| Driving axle | HC16(16 ton) Heavy hub reduction drive axle | ||
| Brake |
Service brake: Brake gap can be adjusted automatically, double circulation air brake system Parking brake: Potential springs pressing on middle and reel wheels Engine brake: Engine exhaust brake(EVB) |
||
| TYRE Size | 12.00-20 tires No. tire: 10+1 spare | ||
| Suspension system | Leaf spring type | ||
| Leaf Spring of Front/Rear | 10/12 | ||
| Air condition includes | YES | ||
| Fuel tank | 300L | ||
| Color | As the customer request | ||
