450mm Min Ground Clearance 4x4 Farm Tractor Agri Farm Machinery Six Cylinder Engine
160hp 450mm Min. Ground Clearance 4x4 Agricultural Farm Tractor Equipment
Description:
Six cylinder engine, turbo charge, inter-cooling, 12 hours rated power: 118kw, fully enclosed cab, air heater, air conditioner, Fast transmission with eight shifts, 24+8 gears, synchronizer shift, unit frame chassis, driving system with modularized structure, famous international brand front axle, construction machinery rear axle, double rear tire, caliper disc brake, PTO shaft rotation speed: 540/1000 r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position, floating control, and suspension mechanism of rear-mounted Category III. Supporting Weichai engine, torque reserve, strong power, low fuel consumption.And, Weichai special desert air cleaner, more advanced performance, high reliability, outstanding performance in the bad environment and heavy load operation.
Packing:
Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.
Competitive Advantage:
1. Full hydraulic steering system, easy to operate and flexible.
2. The side shift is used to make the operation more light.
3. Reinforced semi axle bushing, durable type stronger.
4. The enhanced transmission system has high transmission efficiency and high reliability.
24F+8R gear shifting, reasonable speed matching, high operation efficiency and strong adaptability.
Humanized design, driving more relaxed
5. The man-machine engineering optimization design of the whole vehicle can enhance the safety and comfort of the driver.
6. Three-point suspension system, high lifting force, strong reliability.
7. Enhanced chassis, enhanced gearbox, heavy weight, strong vehicle grip, greater than resistance to soil operations, more efficient.
Detailed Specification:
| Model | KAT1604-F | |||
| Engine | Rated Power/speed | kW/r/min | 118(160)/2200 | |
| Drive Type | / | 4×4 | ||
| Dimension(Length/Width/Height) | mm | 5990/2580(double rear tyre 3510)/3280 | ||
| Wheel Base | mm | 3080 | ||
| Track(Front wheel) | mm | 1888-2122 | ||
| Track(Rear wheel) | mm | 1952-2568 | ||
| Min. Ground Clearance | mm | 450 | ||
| Min. operation weight | kg | 6200 | ||
| Front counter weight | kg | 400 | ||
| Rated Traction Force | kN | 36 | ||
| No. of gears | 24F+8R | |||
| Forward Gear | Speed | km/h | 2-34 | |
| Reverse Gear | Speed | km/h | 2-19 | |
| Tyre Model | Front Tires | / | 14.9-28 | |
| Rear Tires | / | 18.4-38 | ||
| Power-output shaft Type | / | Rear position, independent | ||
| power-output shaft Rated Speed | r/min | 540/1000 | ||
| Max. Lifting force | kN | 36 | ||
