HOWO WD615 Engine Coal Mine Dump Truck 40 Tons 9.726LDisplacement ZZ3257N3447C1
ZZ3257N3447C1 HOWO WD615 engine Euro 2 6X4 40 tons mining dump truck with 9.726LDisplacement
Description:
This model Mining dump Truck is produced by SINOTRUK.It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.
Packing:
The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.And we have rich packing experience and well service.
Competitive Advantage:
1. High quality has always been our advantage.We have perfect transportation methods, which can greatly save your transportation cost.Our semi trailers can transport .
2. Specialization ,standard and accurate meet your requirement.
3. The best quality standard guaranteed
4. supply spare parts (original, OEM, and replacement) for all types of trucks
5. cooperate with efficient logistics which ensure the goods reach you timely and safely.
6. rich experienced team and could provide good after-sales service
| Model | ZZ3257N3447C1 | ||
| Condition | New | ||
| Drive type | 6×4 | ||
| Brand | HOWO Dump Truck | ||
| Steering Wheel Type | LHD(Left hand drive) (RHD is in option) | ||
| Overall Dimension(mm) | 7835×2496×3170 | ||
| The total mass(Kg) | 25000 | ||
| Kerb weight(kg) | 12390 | ||
| Wheel base(mm) | 3425+1350 | ||
| Dimension of cargo body(mm) | L×W×H | 5200×2300×1500 | |
| Thickness of steel plate | Bottom: Side: | ||
| Capacity | |||
| Tipping system | HYVA Front tipping system | ||
| Fuel Type | Diesel | ||
| Engine | Type | SINOTRUK brand,WD615.47 Inline six-cylinder, water-cooled, four-stroke, | |
| Emission standard | EURO II | ||
| Horse power | 371hp | ||
| Maximum output | 273Kw @ 2200 rpm | ||
| maximum torque | 1500N.m | ||
| Displacement(L) | 9.726 | ||
| Cabin | HW76 Cabin with two seats, and one sleeper, air conditioner, | ||
| Steering | German hydraulic steering with power assistance | ||
| Transmission | Manual Type. HW19710 Sinotruk 10 Speed Transmission,10 forward and 2 reverse | ||
| Clutch | Ø430mm dry diaphragm spring diameter clutch Hydraulic boosting | ||
| Front axle | HF9(9 ton), plate (disc) brake | ||
| Driving axle | HC16(16 ton) Heavy hub reduction drive axle | ||
| Brake | Service brake: Brake gap can be adjusted automatically, double circulation air brake system | ||
| TYRE Size | 12.00-20 tires No. tire: 10+1 spare | ||
| Suspension system | Leaf spring type | ||
| Leaf Spring of Front/Rear | 10/12 | ||
| Air condition includes | YES | ||
| Fuel tank | 300L | ||
| Color | As the customer request | ||
