10 Inch Clamp Type Water Purifier Machine With Quick Fitting Filters
Water Purifier Machine 10 inch Clamp type Quick Fitting Filters ( Active Carbon , PP , UF , RO , and so on )
1. 10” PP Sediment Filter
| Size |
Outer diameter: φ62mm Length with filter and clamping head: 268mm Length of filter: 246mm Connector: 1/4＂OD Weight: 222g |
| Working parameter |
Flow rate: 1.0GPM Rated pressure: 120Psi Burst pressure: 450Psi Rated working temp.: 45℃ Total water filtration rate: 2000～4000L |
| Filtration material | Filtration accuracy: 3μm |
2. 10” CTO Block Active Carbon Filter
| Size |
Outer diameter: φ62mm Length with filter and clamping head: 268mm Length of filter: 246mm Connector: 1/4＂OD Weight: 310g |
| Working parameter |
Flow rate: 1.0GPM Rated pressure: 120Psi Burst pressure: 450Psi Rated working temp.: 45℃ Total water filtration rate: 6000～8000L |
| Filtration material | NSF approved block active carbon |
3. 10” GAC Granular Post Active Carbon Filter
| Size |
Outer diameter: φ62mm Length with filter and clamping head: 268mm Length of filter: 246mm Connector: 1/4＂OD Weight: 353g |
| Working parameter |
Flow rate: 1.0GPM Rated pressure: 120Psi Burst pressure: 450Psi Rated working temp.: 45℃ Total water filtration rate: 6000～8000L |
| Filtration material | Coconut shell active carbon imported from Indonesia (12~24mesh, iodine value>1000) |
4. 10” UF Ultra-filtration membrane
| Size |
Outer diameter: φ62mm Length with filter and clamping head: 268mm Length of filter: 246mm Connector: 1/4＂OD Weight: 248g |
| Working parameter |
Flow rate: 1.0GPM Rated pressure: 120Psi Burst pressure: 450Psi Rated working temp.: 45℃ Total water filtration rate: 10000L |
| Filtration material | UF membrane (0.02~0.1μm) |
5. 10” RO Reverse Osmosis membrane
| Size |
Outer diameter: φ62mm Length with filter and clamping head: 268mm Length of filter: 246mm Connector: 1/4＂OD Weight: 290g |
| Working parameter |
Flow rate: 1.0GPM Rated pressure: 120Psi Burst pressure: 450Psi Rated working temp.: 45℃ Total water filtration rate: 20000L Desalination rate: 96% |
| Filtration material | 50GPD Dow membrane (0.0001μm) |
