Normal Temperature BOPP Holographic Film Cigarette Laser Shining Glossy Food Grade
Normal Temperature Holographic BOPP Film Laser Shining Glossy Food Grade Film
Production of BOPP film is made from polypropylene polymer melt through the long and narrow nose first sheet or thick film, and then within the special drawing machine, under certain temperature and the set speed, at the same time two or step by step in the vertical direction (vertical, horizontal) on the drawing, and through the appropriate cooling or heat treatment or special processing (such as corona, coating, etc.) made of thin film.
BOPP film colorless, odorless, tasteless, non-toxic, and has high tensile strength, impact strength, rigidity, toughness and good transparency.
| NO. | Properties | Unit | Value | Test Method | |
| 1 | Standard Thickness | mic | 12 | ||
| 2 | Film Thickness Tolerance | % | ≤ | 5 | ASTM-D374 |
| 3 | Tensile Strength MD | MPa | ≥ | 200 | ASTM-D882 |
| Tensile Strength TD | ≥ | 200 | |||
| 4 | Elongation at Break MD | % | ≥ | 100 | |
| Elongation at Break TD | ≥ | 100 | |||
| 5 | Heat Shrinkage(150℃/30min) MD | % | ≤ | 1.5 | ASTM-D1204 |
| Heat Shrinkage(150℃/30min) TD | ≤ | 0.5 | |||
| 6 | Wetting Tension | mN/m | ≥ | 52 | ASTM-2578 |
| 7 | WVTR | g/m2.24h | ≤ | 3.5 | ASTM-F1249 |
| 8 | OTR | cm3/(m2.24h.0.1MPa) | ≤ | 15 | ASTM-F1927 |
| 9 | Strong adhesive strength | % | ≤ | 20 | --- |
| 10 | Aluminum-plate thickness | Ω/ | ≥ | 2.0 | --- |
| 11 | Aluminum-plate equality | % | ± | 15 | --- |
Contact us
We try our best to achieve technical innovation and diversification of trading all the time, and integrate preponderant factory resource of the domestic and overseas constantly. We have strong technology strength and manufacturing facility, inclduing German Monralan series printing machine group,. Swiss Buster high precision automatic die cutting machine, holographic anti-counterfeiting hot stamping machine, production line of wheel. Manufactureing facilty of PVC heat-sealable film and twisted film use advanced extrusion technology and testing system.
Specification:
| Thickness | OD | Width | Length | Diameter | Inner Core |
| 6-150mic | 2.0-3.0 | ≤2350mm | 3000-36000m/r | ≤800mm | 76mm(3″),152mm(6″) |
FAQ:
1. What is your MOQ?
Normally our MOQ for each size is 1ton. If you think it is too much, we can discuss according to your requirement in details.
2. Can you offer free sample?
Yes, A4 sample for free.
3. What is your delivery time?
We deliver in 10-20days
4. What is your payment?
TT or LC at sight.
5. Can you accept mixed products in one container?
Yes, we accept for sure.
