Cigarette Inner Frame 93-95mm King Size
Single-Sided White Board Paper Cigarette Inner Frame Size 93-95mm King Size
Coated paper has the advantages of white paper surface, good smoothness, high gloss.
Common have one - side coated paper, two - sided coated paper.
Usually referred to as coated paper, refers to the double-sided coated paper.
Do not specify the case, is generally the use of this paper raw material.
The use of single coated paper, it must be explained.
Inner frame helps the cigarette box to maintain the shape. We take the paperboard manufactured in China for our inner frame. The inner frame varies from 210gsm to 250gsm according to the requirement of customers. We not only produce white inner frame, but also produce the colored inner fame and laminated inner frame. Our monthly production capacity of inner frame is 300 tons. The inner frame has very good performance on different cigarette packaging machines such as HLP, GD, and FORKE etc.
Features
• 100% virgin pulp, High printing gloss, Smooth printing surface
• High gloss, Excellent brightness and smoothness, Good runnability
• Competitive stiffness and caliper , True color reproduction
• ISO 9001:2000,ISO14001:2004,SGS,FSC ARE ALL AVAILABLE.
Inner Frame
- Customized cigarette inner frame welcomed.
- We've been exporting cigarette inner frame to over 30 different countries world-wide.
- Our cigarette inner frame has high quality to run smoothly on HLP, FORKE, GD and all other machines.
Now, take action to wholesale the custom 95mm king size white cigarette inner frame for sale from our factory. As a professional manufacturer and supplier, we will offer you good after-sale service and fast delivery.
| ITEM | UNIT | TECHNICAL REQUIREMENT |
| Grammage | g/m2 | 230±10 |
| Thickness | mm | 0.3±0.02 |
| Width | mm | 95±0.5 |
| CD Stiffness | mN.m | ≥3.1 |
| Stiffness MD/CD Ratio | % | ≤ 2.1 |
| MD Folding Endurance | / | ＞15 times |
| △Eab | / | ≤ 3.0 |
| Brightness(Front) | % | ＞78 |
| D65 Fluorescent Brightness | % | ≤ 1.0 |
| Smoothness | S | ≥200 |
| COBB | g/m2 | Top ≤50.0, Back ≤50.0 |
| Moisture | % | 6.0±1.5 |
|
Inner Core |
mm | 120±0.5 |
MATT
| Basis Weight | g/m²±3% | 80 | 90 | 95 | 100 | 105 | 115 | 120 | 128 | 130 | 140 | 150 | 157 | ||||||||||
| Thickness | μm ±4 | 72 | 78 | 83 | 84 | 90 | 100 | 104 | 110 | 111 | 119 | 128 | 140 | ||||||||||
| Brightness | %±2 | 89 | |||||||||||||||||||||
| Opacity | %±1 | 91 | 92 | 94 | 94 | 95 | 96 | 96 | 96 | 97 | 98 | 98 | |||||||||||
| Roughness | μm≤ | 2.7 | |||||||||||||||||||||
| Gloss | % | 35±5 | 32±5 | ||||||||||||||||||||
| Basis Weight | g/m²±3% | 170 | 180 | 190 | 200 | 210 | 216 | 230 | 250 | 260 | 270 | 300 | 350 |
| Thickness | μm ±3% | 156 | 166 | 175 | 184 | 193 | 205 | 212 | 230 | 239 | 257 | 283 | 365 |
| Brightness | %±2 | 89 | |||||||||||
| Opacity | %±1 | 99 | |||||||||||
| Roughness | μm≤ | 2.0 | |||||||||||
| Gloss | % | 35±5 | 30±5 | ||||||||||
Packing Specifications:
By pallets: 36-48 bobbins per pallet, wrapped with plastic films
Pallet size: 1.15mx1.15mx1.15m
Shipment: 20ft/ 40ft container, or LCL shipment
Notes:
Yellow core white card paper is mainly for high-end cigarette packaging market, the products have excellent printing and post-processing, fully meet the requirements of high-speed gravure offset printing flexo printing and other printing methods, as well as stamping film composite transfer and other processing process requirements of product subdivision coating white card paper coating (composite) white card paper
