Transparent High Tensile Strength BOPP Film For Cigarette Outter Package
Transparent High Tensile Strength BOPP Film For Cigarette Outter Package
Introduction:
BOPP Thermal Laminating Film is mainly made of BOPP + EVA.
We use extrusion-coating process to combine these two layers.
In the final film one side has properties of BOPP film and the other side becomes heat sensitive surface used for dry lamination.
This product has two classifications: glossy/shine/transparent and matte/opaque, both of which sees thickness from 14micron to 32micron.
Its width could be from 180mm to 1880mm and length from 150m (1 inch core, 25mm) to 4000m (3 inch core, 76mm).
Information:
| NO. | Product Property | Detail & Description |
| 1 | Material | BOPP |
| 2 | Thickness | 18 um – 25 um |
| 3 | Width | 117mm, 119mm, 120mm, 170mm, 340mm, 345mm, 350mm, 360mm (customized as per request) |
| 4 | Length | 2000 – 4000m |
| 5 | ID of Inner Core | 76mm |
| 6 | Shrinkage | 1%-3%(Low Shrinkage); 4%-6%(Middle Shrinkage); 7%-10%(High Shrinkage) |
| 7 | Density | 0.905 g/cm³, 0.92 g/cm³ |
| 8 | Thickness | 22.0 μ m, 21.0 μ m |
| 9 | Tensile Strength(MD) | 150 N/mm, 175 N/mm, 160N/mm |
| 10 | Tensile Strength(TD) | 275 N/mm, 310 N/mm, 280 N/mm |
| 11 | Elongation at Break(MD) | 180%, 155%, 150% |
| 12 | Elongation at Break(TD) | 70%, 65%, 60% |
| 13 | Heat Shrinkage Rate(MD) | 2.6%, 8.6%, 7.2% |
| 14 | Heat Shrinkage Rate(TD) | 3.0%, 8.8%, 7.0% |
| 15 | Moisture Permeability | 2.0 g/m²/24h |
| 16 | Gloss | 85%, 89%, 90% |
| 17 | Haze | 1.8%, 1.0% |
| 18 | Coefficient of Friction | 0.23, 0.25 |
| 19 | Heat Seal Strength | 2.6 N/15mm, 2.5 N/15mm |
| 20 | Heat Seal Range | 110-160 ℃ |
| 21 | Modulus of Elasticity | 2000 N/mm², 2450N/mm², 2300N/mm² |
Factory Advantages:
1) Our factory is equipped with 2 coating line,4 slitting machine and completed testing instrument.
2) Offer OEM service for global buyer.
3) Proper scale enables us to control the quality better.
4) Near to Guangzhou Port and fast delivery.
5) Directly supply with competitive price.
