Cigarette Long Boxes 350mm Size Cigarette BOPP Film Elongation 340-500 %
Cigarette Long Boxes 350mm Size Cigarette BOPP Film Elongation 340-500 %
TDS
| Property | ASTM Test Method | Cast, Uniaxial Orientation |
| Area factor in 2/lb./1 mil film | – | 30,400–31,300 |
| Specific gravity (g/cm3) | D1505 | 0.885–0.905 |
| Tensile strength (psi) | D882 | 4500–7000 |
| Elongation (%) | D882 | 550–1000 |
| Tear strength (g/mil propagation) | D1922 | 25 MD 600 TD |
| Fold Endurance | D2176 | Very high |
| 24 h % water absorption | D570 | 0.005 |
| Water vapor transmission rate (g/mil/100 in.2/24 h at 100°F) | E96 | 0.7 |
Information Details
|
Bopp Film |
|||||||||
| SPECIFICATION PARAMETER | |||||||||
| SPECIFICATION | 24 GLOSS | 25 GLOSS | 27 GLOSS | 30 GLOSS | 26 MATT | 27 MATT | 28 MATT | 30 MATT | |
| THICKNESS(UM) | BASE | 12 | 12 | 15 | 18 | 15 | 15 | 17 | 18 |
| EVA | 12 | 13 | 12 | 12 | 11 | 12 | 11 | 12 | |
| TOTAL | 24 | 25 | 27 | 30 | 26 | 27 | 28 | 30 | |
| WEIGHT | kg | 45.04 | 43.22 | 40.1 | 36.15 | 42.37 | 41.35 | 39.25 | 37.37 |
| kg | 0.222 | 0.0231 | 0.025 | 0.02766 | 0.0236 | 0.02418 | 0.02548 | 0.02676 | |
| Width | 360 390 440 540 590 780 880 1080 1320 1400 1600 1800 Upon customer's requirement | ||||||||
| Lenghth | 200 - 6,000 more or less 10% allowed | ||||||||
| Corona Treatment Side | A | B | AB(BOTH SIDE) | ||||||
| Connector | Less than 2 | ||||||||
| TENSILE STRENGTH | MD:2.4*106 dyne/cm CD:5.3*106 DYNE/cm | ||||||||
| Paper Core(inter Diameter) | 25.4mm(1')/76mm(3') 155mm(6') | ||||||||
BOPP Film
BOPP transparent film also known as light film, flat film. Used for printing, compounding (transparent type, extinction type), coating (adhesive tape and PVDC coated film base film), it is the most widely used film products, the largest output of the variety; BOPP ordinary film (flat film, light film) is suitable for food packaging, paper composite and general packaging printing composite, is the largest amount of BOPP products in the variety, is widely used in all kinds of printing, composite products for a variety of food, articles packaging use. In the film consumption, the belt film occupies a large proportion, its production characteristics are large output, simple process, low technical requirements.
Operation Guidance
1. Adjust roller pressure and temperature according to different types of paper and ink.
2. When using the film for the first time or changing the usual size, a small trial volume before starting massive lamination is proposed.
3. Normal process temperature is 90C-105C (203F - 221F), roller pressure and temperature vary from different types of paper, ink and machines.
4. Make sure the ink is dry before laminating. It will delaminate when the paper contains too much moisture or powder.
5. Make sure to put the material in place with low temperature and dry.
6. The following situation will affect the final quality of the film during lamination.
a. Using metal ink
b. Ink containing too much wax, dried oil, adhesive, silicon additive and so on.
c. Much too thick ink
d. Ink completely not dried yet.
e. Much too humid paper sheet.
f. Too much powder on the surface
FAQ
1: Do you offer samples?
Yes, we could offer you a free sample, you need to afford the freight yourself.
2: Are there in stock?
Yes,some items are in stock,please contact us for the informations.
3: How to guarantee our quality
1). Before produce: send samples for checking.
2). During producing: send photos and vidio of producing to you.
3). Before shipment: customer's test company come to our factory to inspection of goods or we can send bulk production samples for checking.
4). After shipment: if there any problem about the packing tape, if it's our mistake, we will take responsible.
Cigarette BOPP Film
