High Brightness Advertising Stadium Perimeter Led Display Led Banner 1280x960mm Cabinet
High Brightness Advertising Stadium Perimeter Led Display Led Banner 1280x960mm Cabinet
Features of perimeter display
1. Rubber mask: The rubber mask can protect football player and also protect led display itself;
2. Foam protector on the top of cabinet can also protect players ;
3. Adjustable bracket at the back of cabinet;
4. Quick installation: we have designed side pins for quick installation
5. Good color uniformity, because we use top rate of Led;
6. Energy saving, due to we use high efficiency power supply, top rate of led, etc;
7. Double data backup: if one data cable doesn’t work, perimeter led display still can work well;
8. High refresh rate: more than 3,840Hz;
9. EMC certificate is available;
Specification of perimeter led display
| Model | ST-10 |
| Pixel Pitch | 20mm |
| Unit Size | 1280*960*187mm |
| LED Type | DIP346 |
| Pixel / Unit | 64*48 |
| Unit Weight | 65kg |
| Viewing Angle(H/V) | 110°/40° |
| Application | Storage-40~60° C, Working-20~50° C |
| Protection Level(Front/Rear) | IP65/IP54 |
| Power Consumption( AVG.) | 360W |
| Driving | Static |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >3840Hz |
| Processing | 16bit |
| Max Brightness | >6500nits |
| Power Supply | AC 110/220±10%, 50~60Hz |
| MTBF | ≥ 1000 Hours |
| Life Span | ≥ 100000 Hours |
| Pixel Failure | < 0.0003 |
