Cree Led Chip Soccer Field Advertising Boards Static Driving Good Color Uniformity
High Brightness of 8,000nits Sports Perimeter Led Display Static Driving Led Billboard
Stadium perimeter LED display's Features:
1. Soft mask: We have our own design for soft mask. For one thing, this can protect players and for
another, it can also protect LED panel.
2. Adjustable angle: There is supporter at the back of cabinet. So the view angle can be adjusted accordingly.
3. Soft rubber protector on the top of cabinet: We will put a soft rubber protector on the top of each cabinet to protect players
4. Adjustable angle: There is supporter at the back of cabinet. So the view angle can be adjusted accordingly.
5. Good color uniformity: Since 3 LED chips are encapsulated in one lamp, SMD color uniformity is much better than DIP so the showing effect is perfect.
6. Good waterproof protection: Front is IP65 and back is IP54. There is totally no problem for outdoor application.
7. Big view angle: SMD view angle is bigger than DIP.Its view angle is 160°for horizontal and 110°for vertical.
8. Good color uniformity: Since 3 LED chips are encapsulated in one lamp, SMD color uniformity is much better than DIP so the showing effect is perfect.
9. Energy saving: power consumption is a key factor for LED billboard. BAKO’s LED display is designed with low power consumption to help clients to save energy.
Applications:
Advertising media, sports stadiums, public area, Football game, basketball game, swimming, pool golf game etc.
Parameter:
| Pixel Pitch | 16mm |
| Pixel Density | 3,906dots/sqm |
| Color Configuration | 1R1G1B |
| LED Encapsulation | DIP346 |
| Module Size | 256mm x 256mm |
| Module Resolution | 16dots x 16dots |
| Drive Duty | Static Constant Current |
| Brightness | >8,000nits |
| Viewing Distance | 16m - 160m |
| Viewing Angle | H: 120°, V: 70° |
| Refresh Rate | 2,000HZ |
| Frame Rate | 120frame/sec |
| Grey Grade | 256levels of Each Color |
| Color Grade | 16.7M |
| Power Input | AC110V/ 220V/ 50HZ |
| Max Power Consumption | 1,600W/sqm |
| Ave. Power Consumption | 400W/sqm |
| Storage Temperature | -40℃ - +80℃ |
| Working Temperature | -20℃ - +60℃ |
| Blind Spot Rate | <1/10,000 |
| MTBF | >10,000 Hours |
| Life Span | >100,000 Hours |
| Waterproof | IP65 |
| Operating Humidity | 10% - 95% |
| Control System | Synchronous, Asynchronous |
| Operating System | Win 98, Win2000, XP, 07.etc |
| Input Source | All Format (AVI, MPEG,VOB, RM, etc) |
| Certificate | CE, LVD, RoHS |
