Easy Maintenance Led Ads Display , 104*104px Full Hd Led Display Energy Saving
Full Color Indoor Rental LED Display with fast installation and easy maintenance
Description:
The die casting cabinet 500mm*500mm and 500mm*1000mm are both availble for the indoor P2.976, P3.91, P4.81, P6.25 indoor and outdoor full color led display.
Features:
1. Seamless Combination.
The LED display screen for stage can be installed quickly. The lock system can make the LED modules become flatness.
2. High Brightness
The high brightness and high definition features of LED screen for stage show ensure high quality pictures, making it a perfect fit for stage, banks, station and other activities.
3. Good Material
We purchase raw material from famous brands, such as Nichia, Cree, Silan, Epistar. Good material also perfect the products.
4. Unsurpassed Color Uniformity
Unique color calibration process make the pictures stay natural and colorful.
Advantages:
Thin and Light Cabinet:
Simple , ultra thin and light design ,easy to install and transport
fanless, zero noise, low power consumption, automatic heat dissipation
High Definition and Exquisite Image:
Small-pitch series obtain high contrast and high gray scale, It can realize the HD and exquisite image
Supporting point-to-point correction, to ensure the color and brightness consistency
Exquisite color, clear and natural image with excellent RGB gray scale processing
Low Consumption Energy Saving:
Low power consumption, energy saving ,green and environmental protection.
Technical Parameter:
| Model | IRA-4.8 | IRA-6.25 |
| Pixel Pitch | 4.81mm | 6.25mm |
| Pixel Density | 43264 pixels/m² | 25600 pixels/m² |
| Cabinet Dimension |
500*500mm
500*1000mm |
500*500mm
500*1000mm |
| Cabinet Resolution |
104*104px
104*208px |
80*80px
80*160px |
| Driving Method | 1/13 Scan | 1/10 Scan |
| Frame Refresh | ≥60HZ | ≥60HZ |
| Data Refresh Rate | >1500HZ | >1500HZ |
| Gray Scale | 16bit | 16bit |
| Power Consumption(avg.) | 320w/m² | 320w/m² |
| Input Voltage |
AC 110/220±10%
50-60HZ |
AC 110/220±10%
50-60HZ |
|
Temperature (operating/storage) |
-20~50℃/-40~60℃ | -20~50℃/-40~60℃ |
|
Humidity (operating/storage) |
10%~90%RH/10%~85%RH | 10%~90%RH/10%~85%RH |
| Life Span | ≥50000hrs | ≥50000hrs |
| Pixel Failure | <0.0003 |
<0.0003 |
After-sale service:
1. Our products have two years warranty service.
2. We reply in 24 hours and can solve you problems well.
3. We offer training to our customer who includes operating and maintenance of our products.
4. In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, our company will deploy some spare parts such as power and chips etc.
Shipment:
Delivery Method: Flight case: 4-8 unit display Panels are packaged in one case.
Delivery Time: 20-25 Working Days.
Payment Item: T/T, L/C, West Union.
