Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Light Weight Sports Perimeter Led Display for Stadium Game, High Refresh Rate High Brightnes
Description:
1. High Brightness
More than 1500nits and it can be sawn from long distance.
2. Adjustable Support and Quick Rigging System
Flexible support design makes LED panel lean by multi angles to cater audience’s needs and quick rigging system design makes the installation and dismantle easier and faster.
3. Waterproof and 2 Year Warranty
Water Proof IP65 and 2 year warranty. LED display can work in all-weather condition very well.
Why choose BAKOVISION?
1. more than 10 years experience in led display industry, we have most talented engineers to design best products for our clients;
2. Top quality machines to make top quality products;
3. Most competitive price make our led displays are afordable;
4. For key business partners, we can offer financial credit;
5. We Use Top Rate LED to make best Led display screens, as well as best power supply, high quality signal & power cables, etc.
6. Strict Perfect anti-static precautions: during manufacturing, static electric damage is the most serious problem.
7. Use advanced processing technology, machinery guarantee for high-quality and long-life time products
Specifications
| Parameter | Unit | Value |
| Pitch | mm | 10 |
| Brightness | nits | 1,200 |
| Viewing angle – Horizontal (50% brightness) | deg. | 140 |
| Viewing angle – Vertical (50% brightness) | deg. | 140 |
| Panel width | mm | 1,280 |
| Panel height | mm | 800 |
| Panel depth | mm | 136 |
| Panel area | sq. m. | 1.024 |
| Panel material | Epoxy paint coated aluminum | |
| Panel Mode | Quick Assembly Cabinet with Bracket | |
| Panel protection | Soft mask | |
| Ingress protection (front/rear) | IP | IP21/IP43 |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| Resolution per panel | 128×80 | |
| LED per sq. meter | 10,000 | |
| Recommended minimum viewing distance | m | 6 |
| Recommended best viewing distance | m | 10~40 |
| Colors | 281 Trillion | |
| Grey scale (linear) | Levels | 65,536 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio | 1,000:1 | |
| Processing depth | bit | 16 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3,000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts/ cabinet. | 600 |
| Input power (typical) | Watts/ cabinet. | 240 |
| Multimedia data format | DVI,MPG,AVI,WMV,RM etc. | |
| Data interconnection | UTP Cat 5/Optical Fiber | |
| Mounting system | Stand on ground by bracket |
