SMD3535 P6.25 Outdoor Rental LED Display Screen For Stadiums 1/10 Scan
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
20-25days
Brand:
BAKOVISION
Product Description
P6.25 Outdoor Rental LED Display IP65/IP54 SMD3535 High Gray Scale Lower Power Consumption Die Casting Aluminum
Product description
- Ultra slim and lightweight : 8kg per Cabinet Weight(500x500mm), 14kg per Cabinet Weight(500x1000mm), greatly saves transportation costs and labor costs.
- Rental die-casting aluminum structure: rock solid, not easy to deform.
- Seamless splicing : give you a better visual experience.
- Quick lock system, easy installation : quick installation, complete the installation in a few seconds.
- High refresh rate : >1500Hz,no scanning line when photographed.
- High gray level: 256 RGB each, display 16.7million colors, vivid and perfect video effect.
- High resolution: The most apparent features of the new generation of LED display, clearer picture.
- High contrast ratio : make the picture more delicate.
- Wide viewing angle: both horizontal and vertical viewing angles are 140°
- Working status indicator available.
- Optional of Convex Shaped, Concave Shaped and Wave Shaped screens.
- High Ingress protection: IP65/IP54(front/rear).
- High Brightness: >6500nits,brightness automatically adjusted, Clearly visible even in direct sunlight.
- Lower power consumption: Average Power Consumption is 420w/m²,energy saving and environmental protection.
Our advantage
- Rich experience: established in 2005; familiar with technical and material about LED display.
- Absolute OEM service: providing the most suitable solution for you according to your different demands (such as quality, price and etc.). At least 3 different types in one material are provided for your choice , and with the lowest-cost custom service.
- Powerful R&D ability: excellent engineers are constantly developing new products and improving them.
- Good quality:All products have passed CE, ROHS, FCC certification.
- Thoughtful service: we always serve you heart and soul, striving to make our products meet your demands in maximum degree.
- We guarantee all our LED products for 2 years and provide lifetime maintenance charging only for raw materials. We provide an excellent after-sale service, which contains free training, free CAD drawings, for more convenience and free consultation lifetime.
Technological Parameters:
| Model | ORA-6.25 |
| Pixel Pitch | 6.25mm |
| Pixel Density | 25600 pixels/m2 |
| LED Type | SMD3535 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 500x500mm/500x1000mm |
| Cabinet Resolution | 80*80px/80*160px |
| Cabinet Weight | 8kg/14kg |
| Cabinet Material | die casting aluminum |
| Ingress Protection(front/rear) | IP65/IP54 |
| Brightness | >6500nits |
| Viewing Angle(H/V) | 140°/140° |
| Driving Method | 1/10 Scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1500Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 420w/m2 |
| Input Voltage | AC 110/220±10%, 50~60Hz |
| Temperature(operating/storage) | -20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0003 |
