Shopping Mall Indoor LED Display Poster IP40 Light Weight Multiple Installation
Shopping Mall Indoor LED Display Poster Multiple Installation Light Weight
Key Features:
• Ultra slim edge 6mm, display thickness 35mm VS similar product in the market 45mm(thickness)
• Ultralight 28kg per set VS similar product in the market 32kg per set
• Superior Electrical Features;
• New design, add wheel
Specifications:
| Item | BP-1 | BP-2 |
| Physical Pitch | 1.9 mm | 2.5 mm |
| Pixel Configuration | SMD 1010 | SMD 2020 |
| Pixel Density | 279,936pixels/m² | 169,344pixels/m² |
| Module Dimensions (W × H)(mm) | 280 × 210 | 280 × 210 |
| Panel Dimensions (mm) | 1902 × 572 × 35 | 1902 × 572 × 35 |
| NO .of Modules Per Panel (W × H) | 2 × 9 | 2 × 9 |
| Physical Resolution of Module (W × H) | 144 × 108 | 112 × 84 |
| Physical Resolution of Panel (W × H) | 972 × 288 | 756 × 224 |
| Panel Material | Aluminum | Aluminum |
| Single Cabinet Weight | 32kg | 32kg |
| Processing | 16 bit | 16 bit |
| Colour | 281 trillion | 281 trillion |
| Contrast Ratio | 4000: 1 | 4000: 1 |
| Average Power Consumption | 250 W/ Set | 200 W/ Set |
| Max Power Consumption | 750 W / Set | 600 W / Set |
| Driving Method | 1/27 Dynamic Scan | 1/28 Dynamic Scan |
| Operating Temp/Humidity | -10° - 60°C / 10% - 60% | -10° - 60°C / 10% - 60% |
| Storage Temp/Humidity | -30° - 60°C / 10% - 60% | -30° - 60°C / 10% - 60% |
| Brightness | 1,000 nits | 1,200-1,500 nits |
| Refresh Rate | ≥2,880 Hz | ≥2,880 Hz |
| Vertical Viewing angle | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° |
| IP Rating (Front/Rear) | IP40 | IP40 |
| Frame Rate | 60 fps | 60 fps |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front |
We introduce this product to our customers on ISA Sign Exhibition
Our Service:
1. We guarantee all our display, modules, spare parts for TWO years.
2. We provide technology training for free, which contains the operation and maintenance training of the LED display in the factory.
3. After sales, if you have any problem with our products, you can inform us by E-mail, we will reply to you at once.
4. We can provide the training and technical support for the customer in the factory if the customer asks.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
