Steel / Aluminum SMD P5 Flatness Outdoor Advertising LED Video Wall 920 Hz
Steel/ Aluminum SMD P5 Flatness Outdoor Advertising LED Video Wall
Advantages of P5 LED Video Wall :
In the material selection of outdoor P5 led display, we keep strictly control on the cabinet structure quality which will directly influence the screen flatness.
All modules are cross color enhancing, outdoor full color display for temperature impact test, the results showed that: outdoor full color display can use the power normally under the temperature at -40 °C to +60 °C.
160°super wide horizontal and vertical viewing angle covers more potential customers.
LED Video Wall Advantages:
1. Deep black surface, firm & flat, waterproof mask, make sure the flatness and no distortion. Power and control system back-up technology solution available.
2. Standardized design
Standardized module and cabinet for the outdoor fixed series, including P5, P6,P8 and P10 outdoor led display, reducing the delivery time and saving the maintenance cost for the advertisers.
3. After a dustproof and waterproof tested to reach its target IP65. Brightness of Outdoor Fixed Installation IP65 Waterproof P6 Advertising LED Display is more than 6500 nits.
LED Video Wall Specifications
| BOF-5 | |
| Physical Pitch | 5 mm |
| Pixel Configuration | SMD 2727 |
| Pixel Density | 43,264 pixels/m² |
| Module Dimensions(W*H)(mm) | 250*250 |
| Panel Dimensions(mm) | 1000*1000*150 |
| NO. of Modules Per Panel (W*H) | 4*4 |
| Physical Resolution of Module (W*H) | 52*52 |
| Physical Resolution of Panel (W*H) | 208*208 |
| Panel Material | Steel/ Aluminum |
| Colors | 281 trillion |
| Brightness | >6,500 nits |
| Weight (kg/m²) | 65/45 |
| Processing | 16 bit |
| Refresh Rate | >1920 Hz |
| IP Rating | IP65/ IP54 |
| Viewing Angle | V:160 degree H: 140 degree |
| Expected Lifetime | 100,000 Hrs |
| Operating Temp/Humidity | -20ºC-50ºC/ 10%-90% |
| Storage Temp/Humidity | -20ºC-50ºC/ 10%-90% |
| Avg./ Max. Power Consumption | 360/900W/ panel |
| Servicing | Front/Rear |
LED Video Wall Procesure Details
Safety and environmental protection
This P5 outdoor full color advertising LED display screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, it is an ideal product for any kind advertisements.
Widely Application:
Our products have been widely used in venues as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc.
Best After-sale Service
Within 2 year, supply spare parts for free problem.If your LED Screen is defected and is in warranty period, we offer you free accessories for the product. Whenever you need us, we are always there for you. Our support staff is more than willing to assist you for any query or concern. Feel free to contact us any time.
Our company
LED Vision Technology Limited , started in Shenzhen in 2005, fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.Main markets are among America, Europe, Middle East and Asia.
Trade Terms
1.Payment:T/T,30% deposits before production,70% balance to be paid before dleiverying
2.Shipping freight are quoted under your requests
3.Shipping port:ShenZhen,Mainland China
4.MOQ:1pc
