Waterproof Outdoor Rental LED Display P3.91-P6.25 Curved Angle High Brightness
Outdoor Waterproof High Brightness Rental LED Video Display
Rental Led Screen Quick Details:
1, Pixel Pitch: P3.91 - 6.25mm
2, Full colors: 281trillions.
3, SMD, Wide viewing angle: 160°/ 140°.
4, Standard cabinet size: 500×500mm/500x1000mm weight: 25kg/Sqm.
5, Recommended minimum viewing distance: 5m.
6, Warranty: 2 years.
Rental Led Screen Description:
Bako Vision Outdoor LED Screen include permanent installation outdoor electronic led display, the pixel various from 2.6, 3.91mm, 4.81mm, 6mm,10mm. We provide variable solution to satisfy your requirement. You can use it for stage performance or living show. Even you can use it as floor screen.
Rental Led Screen Superior Electrical Features
- Curved angle : ±15° adjustable, creative design to meet your requirement;
- High brightness: More than 6000nits,visible from every direction even face to direct sunshine.
Light sensor can adjust the brightness at night and gloomy weather, this also can save the power cost. - High waterproof grade: IP65 protection, can be sustain strong strom and rain, have the best waterproof ability in outdoor use,SMD LEDs, wide viewing angle, Hor. Ver. 140 degree;
- Convenient Assemble : Smart fast side locks make screen assemble fast and easier; Save your labor cost and time.
- Seamless connection: superior color uniformity and stunning image quality, there is not black bezel line on connection nor information missing;
- Good heat dissipation: New cabinet design of LED screen without fan, good heat dissipation,due to die-casting alumium material ,concise, slim and light weight;
- Convenient Control: Digital Video walls can be connected with nearly any equipment , including to PCs, DVD and camera . That is conveniently for you to present your data;
- High Quality : we use famous IC ,like MBI5020,MBI5024,MBI5030 and high quality lamp, Nationstar and so on, ensure high brightness;
Rental Led Screen Specification
| Physical Pitch | 3.91mm | 4.81mm | 5.95mm | 6.25mm |
| Pixel Configuration | SMD1921 | SMD2525/2727 | SMD2727 | SMD2727 |
| Pixel Density | 65,536 pixels/Sqm | 43,264 pixels/Sqm | 28,224 pixels/Sqm | 25,600 pixels/Sqm |
| Module Dimensions(W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 500 x 80 / 500 x 1000 x 80 | 500 x 500 x 80 / 500 x 1000 x 80 | 500 x 500 x 80 / 500 x 1000 x 80 | 500 x 500 x 80 / 500 x 1000 x 80 |
| NO. of Modules Per Panel (W x H) | 2 x 2 / 2 x 4 | 2 x 2 / 2 x 4 | 2 x 2 / 2 x 4 | 2 x 2 / 2 x 4 |
| Physical Resolution of Module (W x H) | 64 x 64 | 52 x 52 | 42 x 42 | 40 x 40 |
| Physical Resolution of Panel (W x H) | 128 x 128 / 128 x 256 | 104 x 104 / 104 x 208 | 84 x 84 / 84 x 168 | 80 x 80 / 80 x 160 |
| Processing | 16bit | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000 : 1 | 4,000 : 1 | 4,000 : 1 | 4,000 : 1 |
| Operating Temp/Humidity | -20℃ - 60℃ / 10℃ - 60℃ | -20℃ - 60℃ / 10℃ - 60℃ | -20℃ - 60℃ / 10℃ - 60℃ | -20℃ - 60℃ / 10℃ - 60℃ |
| Storage Temp/Humidity | -30℃ - 60℃ / 10℃ - 60℃ | -30℃ - 60℃ / 10℃ - 60℃ | -30℃ - 60℃ / 10℃ - 60℃ | -30℃ - 60℃ / 10℃ - 60℃ |
| Refresh Rate | ＞1,920 Hz | ＞1,920 Hz | ＞1,920 Hz | ＞1,920 Hz |
| Brightness | ≥4,000nits | ≥4,000nits | ≥6,000nits | ≥6,000nits |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front / Rear | Front / Rear | Front / Rear | Front / Rear |
| IP Rating (Front/Rear) | IP 65 / IP 54 | IP 65 / IP 54 | IP 65 / IP 54 | IP 65 / IP 54 |
| Scan Method | 1/16 Scan | 1/13 Scan | 1/17 Scan | 1/8 Scan |
Rental Led Screen Case:
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
