IP21 Indoor LED Advertising Screen , Full Color LED Video Wall For Meeting Room
Indoor Fixed LED Display Advertising LED Screen, Full Color Video Wall for Meeting Room
Indoor Fixed LED Display Specification:
Coventional and Creative
Conventional pitched and panel available
Concave, convex, cylinder shapes available
Steel or aluminum panel, front or rear access
Unsurpassed Color Uniformity
Unique color calibration process
Tight bin selection for LED wavelength
Deep black levels, contrast ratio 4000:1
Various Mountings
Front installation for most of wall mounting
Simple connection, easy operation
Wide View Angle
Selected LED and mask to broaden viewing angle
160° horizontal and vertical wide viewing angle
Indoor Fixed LED Display Parameter:
| Model | BIF-3 |
| Pixel Pitch | 3mm |
| Pixel Density | 111111 pixels/m² |
| LED Type | SMD2121 |
| LED Configuration | SMD |
| Cabinet Dimension | 960*960 |
| Cabinet Resolution | 192*192 |
| Cabinet Weight | 9 kg/panel |
| Cabinet Material | Steel/Aluminum |
| Ingress Protection(front/rear) | IP21 |
| Brightness | 900~1200nits |
| Contrast ratio | 4000:1 |
| Colours | 281 trillion |
| Viewing Angle(H/V) | 160°/140° |
| Driving Method | 1/32 Scan |
| Power Consumption(avg.) | 120w/m² |
| Power Consumption(max.) | 400w/m² |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | 1920 Hz |
| Gray Scale | 16bit |
| Power Supply | AC 110/220±10% 50~60Hz |
| Temperature (operating/storage) |
-10~60°C -30~60°C |
| Humidity(operating/storage) | 10%~60%RH 10%~65%RH |
| Life Span | 10000 Hours |
| Service | Front/Rear |
Advantage:
Our company also can arrange our engineers to provide you professional installation guide and training for free via remote control, video and phone.
All of products will be tested many times and 100% promise the products are well before shipping.
The products can be customized according to your projects and offer you the CAD drawing for free.
We guarantee all of our displays, modules, spare parts for full two years. During the time, we will replace or fix our goods for free if there is something wrong with them.
Service
1.24-hour hotline service, including counseling and technical guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Warranty service.
7. Engineering technical service.
FAQ:
Q1. Can I have a sample order for LED Display?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 10-15days for order quantity more than
Q3. Do you have any MOQ limit for LED light order?
A: Low MOQ, 1PC for sample checking is available
Q4. Is it OK to print my logo on LED light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
