P1.25 P1.56 P1.87 P2.3 Indoor Fixed LED Display For Advertising
P1.25 P1.56 P1.87 P2.3 Indoor Fixed LED Display For Advertising
High Refresh Rate P1.25/P1.56/P1.87/P2.3 Indoor Fixed LED Panel Screen/LED Display for Advertising
Led Screen Quick Details:
1, Pixel Pitch:1.25mm,1.56mm,1.87mm,2.3mm
2, Full colors: 281trillions.
3, SMD, Wide viewing angle: 160°/ 140°.
4, Standard cabinet size: 600 x 337.5mm / 640 x 480mm
5, Recommended minimum viewing distance: 2m.
6, Warranty: 2 years.
Rental Screen Features and Advantages:
- This product designed with die-casting aluminum, which makes it more stable and effective.
Lightweight makes it easy to operate and install.
- The special splicing design realizes a variety of styles, so that the products meet the diverse requirements of customers.
- Our products perform well in waterproof, antifreeze and high temperature resistance.
- The product has been passed the dust-proof and water-proof, achieving protection standards IP43.
- All module edges have made strong compression, which makes the cabinet have better flatness and is not easily deformed.
- The box with a sliding iron top, bottom chute, and optional locking device to fine-tune the gap and ensure seamless between the boxes. Please do not squeeze the entire screen which ensure good surface smoothness
Rental Screen Specification:
| UHD-1.2 | UHD-1.5 | UHD-1.8 | UHD-2.3 | |
| Physical Pitch | 1.25mm | 1.56mm | 1.87mm | 2.34MM |
| Pixel Configuration | SMD1010 | SMD1010 | SMD1010 | SMD2121 |
| Pixel Density | 648,000 pixels/Sqm | 410,881 pixels/Sqm | 286,225 pixels/Sqm | 182,329 pixels/Sqm |
| Module Dimensions(W x H) (mm) | 150 x 168.75 | 150 x 168.75 | 150 x 168.75 | 150 x 168.75 |
| Panel Dimensions (mm) | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 |
| NO. of Modules Per Panel (W x H) | 4 x 2 | 4 x 2 | 4 x 2 | 4 x 2 |
| Physical Resolution of Module (W x H) | 120 x 135 | 96 x 108 | 80 x 90 | 64 x 72 |
| Physical Resolution of Panel (W x H) | 480 x 270 | 384 x 216 | 320 x 180 | 256 x 144 |
| Panel Material | Die-Casting | Die-Casting | Die-Casting | Die-Casting |
| Single Cabinet Weight | 6 kg/panel | 6 kg/panel | 6 kg/panel | 6 kg/panel |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000 : 1 | 4,000 : 1 | 4,000 : 1 | 4,000 : 1 |
| Average Power Consumption | ≤300 W/㎡ | ≤300 W/㎡ | ≤300 W/㎡ | ≤300 W/㎡ |
| Max Power Consumption | ≤600 W/㎡ | ≤600 W/㎡ | ≤600 W/㎡ | ≤600 W/㎡ |
| Brightness | 600-800 nits | 600-800 nits | 600-800 nits | 600-800 nits |
| Refresh Rate | ≥2,880 Hz | ≥2,880 Hz | ≥2,880 Hz | ≥2,880 Hz |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° | 140° | 140° |
| Expected Lifetime | ≥100,000 Hrs | ≥100,000 Hrs | ≥100,000 Hrs | ≥100,000 Hrs |
| Operating Temp/Humidity | -20℃ - 50℃ / 10℃ - 90℃ | -20℃ - 50℃ / 10℃ - 90℃ | -20℃ - 50℃ / 10℃ - 90℃ | -20℃ - 50℃ / 10℃ - 90℃ |
| Storage Temp/Humidity | -40℃ - 60℃ / 10℃ - 85℃ | -40℃ - 60℃ / 10℃ - 85℃ | -40℃ - 60℃ / 10℃ - 85℃ | -40℃ - 60℃ / 10℃ - 85℃ |
| IP Rating (Front/Rear) | IP 40 / IP 21 | IP 40 / IP 21 | IP 40 / IP 21 | IP 40 / IP 21 |
| Scan Method | 1/45 1/27 Scan | 1/27 Scan | 1/30 Scan | 1/24 Scan |
| Certification | CCC, CE, ETL,TUV | CCC, CE, ETL,TUV | CCC, CE, ETL,TUV | CCC, CE, ETL,TUV |
LED Screen Case
Package
We use carton with foam sheet and cabinet with wooden case/flight case.
We will choose the most practical package as to customer's requirements.
1) Carton with foam plate / EPE
2) Neutral packaging without logo
3) Anti-shaking wooden case package for sea shipment.
4) Flight case package with convenient transportation.
5) Customized package can be designed and made.
FAQ:
1) Q: How can I place an order and how it works?
A: Generally, first, we could make samples for customers, according to the artworks, affirmed material, processing or workmanship. After the sample is confirmation, we will produce the mass production. And, meanwhile, we will show you the pre production.
2) Q: What's the shipment method?
A: We often use DHL, FEDEX. UPS, TNT or Sea Shipping to ship our products.
3) Q: What's the payment method?
A: You can pay by L/C, T/T, Western Union
4) Q: Can I have samples to test the quality?
A: Yes, you can buy any sample to test the quality.
5) Q: What's the delivery time and can you lower the price?
A: It depends on your order and which shipping way you choose.The delivery time is usually within 25-30 days. If you have placed an order of large quantities, then, of course, the price can be lowered.
