Cattle Poultry Feed Making Machine Customized Voltage 300rpm Ring Die Speed
Rabbit Sheep Horse Cow Cattle Feed Pellet Making Machine In Stock
SZLH250 feed pellet making machine Advantages
1) High efficiency
Stable and classical gear driving,non-slipping,can really ensure the production output. Low noise,optimized ring die,maximum output.
2) Hygiene and safety
CE certified standard design and available stainless conditioner for feed,human and machine safety.
3) Flexible production
Wide product rangeΦ1.5mm-Φ12mm pellets,conditioner with molasses and steam adding function.
4) User-friendly operation
Hydraulic system for ring die change and roller adjustment(optional),quick ad precise operation；auto-lubrication system(optional)and die & roller lifting device,save labor；on-site touch screen control.
Introduction and Application of feed pellet making machine
This type is SZLH250,capacity is 1.5-2.5t/h ring die feed pellet machine. Can be single used or apply to animal feed pellet line.
Make pellets for chicken, bird, duck, rabbit, pig, cattle, cow, sheep, horse etc. Popular among Customers. Can equipped force-feeding device for Customers.
Technical Parameters of SZLH 250 feed pellet making machine
| Items | SZLH250 |
| Production Capacity | 1.5-2.5t/h |
| Power of Main Motor | 22kw |
| Power of Feeding Screw Motor | 0.75 KW |
| Power of conditioner Motor | 1.5 KW |
| Diameter of ring die | Φ250mm |
| Speed of ring die(r/min) | 300rpm |
| Speed of feeding screw | 12-120rpm |
| Speed of stirrer | |
| Pellet specification | φ2,φ3,φ4,φ4.5,φ5,φ6,φ8,φ10mm |
| Amount of roller | 2 |
| Diameter of roller | Φ110mm |
| Shaping rate of pellet | ≥ 95% |
| Pulverization rate of pellet | ≤12% |
| Stability of pellet in the water | ≥20min |
| Noise (dB(A)) | ≤85dB(A) |
| Working temperature of ring die | ≤85℃ |
| Working pressure of steam | 0.3Mpa |
| Steam consumption(t/h) | 0.05 |
| Temperature of steam(℃) | 130-150℃ |
| Shape dimension | 2250*1430*2040mm |
| Machine weight | |
| Voltage | 3phase 380V,50Hz Can be customized) |
| Control cabinet | Included |
