High Efficiency Feed Pellet Making Machine 1.5 - 2.5t/H Capacity 22kw Main Motor Power
Single Use Or Apply To Chicken Feed Mill Equipment Feed Machine
Features of SZLH250 Chicken Feed Mill Equipment Feed Machine
1. High efficiency
Stable and classical gear driving, non-slipping, can really ensure the production output. Low noise, optimized ring die, maximum output.
2. Hygiene and safety
CE certified standard design and available stainless conditioner for feed, human and machine safety.
3. Flexible production
Wide product rangeΦ1.5mm-Φ12mm pellets, conditioner with molasses and steam adding function.
4. User-friendly operation
Hydraulic system for ring die change and roller adjustment(optional), quick ad precise operation; auto-lubrication system(optional)and die & roller lifting device, save labor; on-site touch screen control.
Brief Introduction of Chicken Feed Mill Equipment Feed Machine
This type is SZLH250,capacity is 1.5-2.5t/h ring die feed pellet machine. Can be single used or apply to animal feed mill equipment.
Can Make pellets for chicken, bird, duck, rabbit, pig, cattle, cow, sheep, horse etc. If Customers materials have grass,
Technical Parameters of Chicken Feed Mill Equipment Feed Machine
| Items | Technical Parameter (SZLH250) |
| Production Capacity | 1.5-2.5t/h |
| Power of Main Motor | 380V 50Hz 3 Phase 22 KW (Can be customized) |
| Power of Feeding Screw Motor | 0.75 KW |
| Power of Conditioner | 1.5 KW |
| Inner Diameter of ring die | Φ250mm |
| Efficient width of ring die | 80mm |
| Speed of ring die | 300rpm |
| Speed of feeding screw | 12-120rpm |
| Speed of Conditioner | 350rpm |
| Pellet specification | φ2,φ3,φ4,φ4.5,φ5,φ6,φ8,φ10mm |
| Amount of roller | 2 |
| Diameter of Roller | Φ110mm |
| Pellet Ratio of Briquetting | ≥ 95% |
| Percentage of powdered Pellet | ≤12% |
| Stability of pellet in the water | ≥20min |
| Noise | ≤85dB(A) |
| Working temperature of ring die | ≤85℃ |
| Working pressure of steam | 0.3Mpa |
| Steam consumption | 50kg/H |
| Temperature of steam | 130-150℃ |
| Packing Size (length×width×height) | 2450*1550*2200mm |
| Machine Size | 2250*1430*2040mm |
| Net/Gross Weight | 1150KG/1445kg |
