Dry Type Single Screw Fish Food Pellet Making Machine 600kg/H
DGP120B Dry Type Single Screw Shrimp Fish Food Pellet Making Machine
Introduction of Fish Food Pellet Making Machine
This fish feed pellet machine is suitable for making floating fish feed and other pet food with different shapes by changing different molds. The main material for making fish feed is maize powder and wheat flour. And we also can offer the whole line to making fish feed.
It mainly consists the following parts:raw material-crusher-mixer-extruder-dryer or cooler(dryer has better effects, if you want to save cost, had better choose dryer)-flavoring parts(selectable)-packer.
Advantages of Fish Food Pellet Making Machine
1. This fish feed extruder is widely used for producing floating feed pellets of all kinds of aquatic animal.
2. Advanced technology and humanized design ensures easy operation and reliable performance.
3. High efficiency, low power consumption
4. Screw sleeve of this fish feed extruder adopts enchase alloy steel strip structure, which guarantees long service life.
5. Different moulds can be chosen to make pellets with different diameters and shapes.
6. Feed pellets dia. Is 0.9-15mm.
Technical Parameters of Fish Food Pellet Making Machine
| Name | Power (kw) | Capacity (kg/h) | Dimension(mm) | Weight(kg) |
| Crusher | 15 | 500-700 | 1600*1050*1300 | 320 |
| Mixer | 4.0kw | 200kg/batch,Time:15 | 1650*1050*1450 | 350 |
| DGP120-B floating machine | Main power:55kw Feeder Power:1.1 cutter power:1.5 | 500-600 | 2400*1950*1600 | 1700 |
| Dryer | heating power:26-28kw;fan power:0.75kw;Mesh belt power:3.0kw | 200-400 | 750*650*1850 | 150 |
| counter-current cooler | Fan power:4.0kw discharge method:pneumatic discharge | 300-500kg/batch, Time is:20minutes | 3500*1300*2400 | 1250 |
| Quantity scale | 1.1 | ≤300bag/h;1-50kg/bag | 2750*950*2940 | 586 |
| Control system |
