220kw Feed Pellet Making Machine 8T/H Animal Feed Equipment
10 T/H Livestock Animal Feed Produce Line Machine
Description of Livestock Animal Feed Produce Line Machine
The complete line including: Raw materials of receiving, cleaning, crushing system, System of batching&mixing, System of pelleting & cooling, System of packing, System of Auxiliary(Air compressor, Steam supply system, Liquid adding machine, Electricity Hoist)
Feed Pellet Size: 0.9-12mm
Feed Pellet Forming Rate: >95%
Feed pellet line raw materials can include corn, wheat, grass, alfalfa, oil seed meal & cakes, pasture, bone meal, microelements, etc.
Application: The final pellet can apply to Poultry feed, livestock cattle sheep pig feed.(According Customers need, the plan will different)
Our factory also supply steel structure and Silos for Customers.
Technical Parameters of Livestock Animal Feed Produce Line Machine
| 10 T/H Automatic Feed Pellet Production Line | |||
| No. | Product name | Model | Power(kw) |
| 1. material receiving section | |||
| 102 | pulse dust collector | TBLFa.18 | |
| 105 | granule material clean sieve | SCY80 | 0.75 |
| 106 | permanent magnetic | TXCT25 | |
| 108 | powder cleaner | SCQZ80 | 11 |
| 109 | permanent magnetic | TXCT25 | |
| 2. material grinding section | |||
| 206 | Impeller feeder | SYLW3 | 1.5 |
| 207 | series tear-circle hammer mill | SDH-ZW50C | 132 |
| 210 | seal screw conveyor | SWLL25 | 6 |
| 3. batching and mixing section | |||
| 313 | double shaft high efficient mixer | SSHJ.2 | 18.5 |
| 314 | scrapper conveyor | TGSU25 | 3 |
| 315 | Bucket elevator | TDTG48.28 | 5.5 |
| 316 | powder material clean sieve | SCQZ75×65×1 40 | 7.5 |
| 317 | permanent magnetic drum | TXCT30 | |
| 4. pelleting section | |||
| 408 | Pellet machine | SZLH420 | 110 |
| 410 | counter-current cooler | SKLN6 | 1.5 |
| 410-1 | crusher | SSLG20×170 | 15 |
| 415 | classic sieve | SFJH125 | 3 |
| 5. packing section | |||
| 501 | Finished product bin | ||
| 506 | automatic packing scale | SDBY-P | |
| 507 | seal conveyor machine | TFKB40 | 3 |
| 509 | pulse dust collector | TBLFa.24 | |
| 510 | seal machinery | 0.75 | |
| 6.auxiliary system | |||
| 601 | Air compressor | 22 | |
| 603 | liquid adding machine | SYTV32 | 3 |
| 604 | liquid adding pipeline | ||
| 606 | boiler system | ||
