2.5T/H Chicken Pigeon Poultry Feed Mill Plant 12mm Feed 70KW
Price:
Negotiable
MOQ:
1 set
Delivery Time:
15-30 working days
Brand:
Strongwin
Product Description
2.5 T/H Chicken Bird Duck Pigeon Poultry Feed Mill Plant
Full set poultry feed mill plant including: Crusher grinder system, mixing system, pellet cooler sieve system, packing sysytem and transport system. According to Customers need, our engineers will design plan for you.
This is SZLH250, capacity is 1.5-2.5t/h poultry feed mill plant, can make pellets for kinds of animals. widely apply to small and middle farm, factorys.
Technical Parameters of SZLH250 Poultry Feed Mill Plant
| No. | Product | Type | Power(KW) |
| 1.Raw materials receiving and crushing and mixing system | |||
| 101-1 | Screw Conveyor | TLSS16 | 2.2 |
| 101-2 | Screw Conveyor | TLSS20 | 3 |
| 103 | Imitation grinder (including iron remover) | SFPZ56*30 | 18.5 |
| 104 | U-shaped ribbon horizontal mixer | LHY1.0 | 7.5 |
| 2.Pelleting system | |||
| 201 | Screw Conveyor | TLSS20 | 3 |
| 202 | To be granulated bin (including window) | 1.0m³ | |
| 203 | Pellet Machine(include control box) | SZLH250 | 11*2+2.2+0.75 |
| 3.Cooling system | |||
| 301 | Skirt belt conveyor | QBPS400 | 2.2 |
| 302 | Buffer bucket | 0.2m³ | |
| 303 | Stainless steel air shutter | GFY250 | 1.1 |
| 304 | Counter Flow Cooler | SKLN1.0 | 0.75 |
| 305 | Air Blower | 4-72No4A | 5.5 |
| 306 | Unloader | XL60 | |
| 307 | Wind shut | GFY215 | 0.75 |
| 308 | Vibrating screen | SFJZ60*1d | 0.25 |
| 4.Screening and packaging system | |||
| 401 | Skirt belt conveyor | QBPS400 | 2.2 |
| 402 | Buffer bucket | 0.5m³ | |
| 403 | Packing scale with sewing bag | 2.2 | |
| Optional | Simple oil filling system (including pipes and nozzles) | SYVT32 | 1.5 |
| Air compression system | 3 | ||
| Boiler with link system | 0.3t/h | 3 | |
| Crumbler machine | SSLG15×80 | 5.5 | |
| Price | Welcome contact us for latest price | ||
