Nightseer Series Thermal Imaging Scope With Rugged 1200G Recoil Resistance
Nightseer Series Thermal Imaging Scope With Rugged 1200G Recoil Resistance For Military Use
Description
Features
▼Each Unit Recoil Tested Before Leaving Factory
▼ Performance at an extreme temperature range of -25° – +50°C.
▼ No import & export restriction
▼ Limited 2-year warranty
Technical Data
| Technical Data Sheet of NS3 Series | ||
| NS335-C | NS350-C | |
| Detector | ||
| Resolution | 384×288 | |
| Frame Rate | 50Hz | |
| Pitch | 17um | |
| Spectral range | 8-14um | |
| NETD | Less than 50mk | |
| Optical Characteristics | ||
| Objective Lens | 35mm | 50mm |
| Magnification | 1X | 1X |
| FOV | 10.6°×8.0° | 7.4°×5.6° |
| Close-up range | 5m | 5m |
| Funtions | ||
| Palette | 10 optional | |
| Start up time | Less than 5 seconds | |
| Image Enhancement | DDE | |
| Contrast and Brightness | AGC | |
| Display | ||
| Type | OLED | |
| Resolution | 1024×768 | |
| Power Supply | ||
| Battery Type | 2XCR123 | |
| External Power Supply | 5v micro USB | |
| Battery Life | 5h | |
| Physical Characteristics | ||
| Weight without batteries | 435g | 465g |
| Size | 150mm×61mm×67mm | 162mmx61mmx67mm |
| Environment Compatibility | ||
| Water Proof | IP66 | |
| Operation Temperature | —25°C~+50°C | —25°C~+50°C |
| Storage Temperature | —40°C~+70°C | —40°C~+70°C |
| Shock Tolerance | 1200g/2ms | |
Packing
What's in the box
Nightseer 335C
Portable Bag
Clip on Eyepiece
Video / RS232 Cable
Warranty Card
Manual
Cleaning Clot
Wireless Keyboard (Optional)
Monocular Eyepiece (Optional)
Thermal Clip On Quality Control
We understand that lives may depend on the performance of our products, that is why every unit that leaves our facility must pass tough quality control standards testing.
It is our mission to continue to design, build, test and ship the very best optoelectronics devices on the market.
