SED-3M 3 Square Meters Power 380V/50HZ/100A Big Box Type Vacuum Commercial Freeze Dryer Vegetables Fruits Machine
SED-3M 3 Square Meters Power 380V/50HZ/100A Big Box Type Vacuum Commercial Freeze Dryer Vegetables Fruits Machine
Product Overview of Freeze Dry Machine
Laboratory freeze dryer is developed for biotech, pharmaceutical and other industry R&D. Drying capacity up to 12 Liters, more customized design according to user's requirement.
Product Parameters of Freeze Dry Machine
| model | 3 square meters |
| Power | 380V/50HZ/100A |
| Power consumption | 19Kw |
| Cooling water qty |
≥3m3/h(T≤28℃) ≥2m3/h(T≤20℃) |
| Compressed air | ≥40L/Min(P=0.4-0.5Mpa) |
| Defrost water consumption | 60Kg/Batch(T=80℃/P≥0.2-0.3MPa) |
| Chamber design temperature | 90℃ |
| Shelf total usable area | 3.24M2 |
| 3-5ml vials capacity | 13000 bottles |
| Structure | Integral |
| Total weight | 2000kg |
| Whole volume | 3500X1200X2100mm |
Feature of Freeze Dry Machine
1. Compact design, easily moving;
2. Simple operation, suitable for R&D purpose;
3. No need any utility apart from power;
4. Maintenance free;
5. Lower temperature with cascade refrigeration system;
6. Stoppring system available.
Show of Freeze Dry Machine
Application of Freeze Dry Machine
Suitable for heating, curing and drying of materials and products in pharmaceutical, chemical, food, light industry and other fields: raw materials, APIs, traditional Chinese medicines, powders, crude drugs, packaging bottles, pigments, dyes, dehydrated vegetables, food, plastic resins, components Parts, paint, wool, salt, catalyst, etc.
