Grey Silicone Impregnated Insulation Fabric 14oz, Ideal for Equipment Covers & Safety Jackets
14 OZ Insulation Material Grey Silicon Glass Fiber Cloth For Covers And Jackets
Description:
Suntex fiberglass cloth is a woven fabric manufactured from texturized fiberglass yarn. The texturization provide enhanced insulation property. Suntex fiberglass cloth is an ideal material for various thermal and acoustic insulation, high temperature seal and protection.
In addition to a range of fiberglass textiles, Mid-Mountain offers high-temperature resistant fiberglass fabrics specifically used in the insulation industry for removable/reusable insulation blankets and pads. With excellent thermal insulation properties, these fiberglass fabrics are heat-treated to reduce fraying during fabrication, have low smoke emission, and excellent abrasion resistance.
Parameter List:
| BASE FABRIC | Base fabric style No. GF430P | ||
| (metric) | (English) | Test methods | |
| Weave | 4H Satin | Crowfoot | |
| COATED FABRIC | Coating style No. SI123-1008 | ||
| Coating | Silicone rubber 1 side | ||
| Weight | 510 ± 25 g/m2 | 15.0 ± 0.74 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.43± 0.02 mm | 0.016 ± 0.0007 inch | ASTM D1777-96 |
| Color | silver grey | ||
| Fire resistance | Flame retardant | ||
| Temp resistance |
Glass fabric up to 5500C (10000F) |
||
Main Application:
Diesel Engine Exhaust Covers
Fire-resistant doors
Turbine Insulation
Thermocouple Insulation
Furnace pads and separators
Advantage:
- Heat, spark and flame resistant, temperature rating 1000°F
- Chemical resistant
- Low thermal conductivity
- High tensile strength, no stretch or shrink
- High dielectric strength
![]()
